How to Deploy Microservices with Docker

Updated by Bob Strecansky Contributed by Bob Strecansky

Contribute on GitHub

Report an Issue | View File | Edit File

Deploying Microservices with Docker

What is a Microservice?

Microservices are an increasingly popular architecture for building large-scale applications. Rather than using a single, monolithic codebase, applications are broken down into a collection of smaller components called microservices. This approach offers several benefits, including the ability to scale individual microservices, keep the codebase easier to understand and test, and enable the use of different programming languages, databases, and other tools for each microservice.

Docker is an excellent tool for managing and deploying microservices. Each microservice can be further broken down into processes running in separate Docker containers, which can be specified with Dockerfiles and Docker Compose configuration files. Combined with a provisioning tool such as Kubernetes, each microservice can then be easily deployed, scaled, and collaborated on by a developer team. Specifying an environment in this way also makes it easy to link microservices together to form a larger application.

This guide shows how to build and deploy an example microservice using Docker and Docker Compose.

Before You Begin

You will need a Linode with Docker and Docker Compose installed to complete this guide.

Install Docker

These steps install Docker Community Edition (CE) using the official Ubuntu repositories. To install on another distribution, see the official installation page.

  1. Remove any older installations of Docker that may be on your system:

    sudo apt remove docker docker-engine docker.io

  2. Make sure you have the necessary packages to allow the use of Docker’s repository:

    sudo apt install apt-transport-https ca-certificates curl software-properties-common

  3. Add Docker’s GPG key:

    curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo apt-key add -

  4. Verify the fingerprint of the GPG key:

    sudo apt-key fingerprint 0EBFCD88


    You should see output similar to the following:

    pub   4096R/0EBFCD88 2017-02-22
          Key fingerprint = 9DC8 5822 9FC7 DD38 854A  E2D8 8D81 803C 0EBF CD88
    uid                  Docker Release (CE deb) <docker@docker.com>
    sub   4096R/F273FCD8 2017-02-22

  5. Add the stable Docker repository:

    sudo add-apt-repository "deb [arch=amd64] https://download.docker.com/linux/ubuntu $(lsb_release -cs) stable"

  6. Update your package index and install Docker CE:

    sudo apt update
    sudo apt install docker-ce

  7. Add your limited Linux user account to the docker group:

    sudo usermod -aG docker exampleuser


    You will need to restart your shell session for this change to take effect.

  8. Check that the installation was successful by running the built-in “Hello World” program:

    docker run hello-world


Install Docker Compose

  1. Download the latest version of Docker Compose. Check the releases page and replace 1.21.2 in the command below with the version tagged as Latest release:

    sudo curl -L https://github.com/docker/compose/releases/download/1.21.2/docker-compose-`uname -s`-`uname -m` -o /usr/local/bin/docker-compose

  2. Set file permissions:

    sudo chmod +x /usr/local/bin/docker-compose


Prepare the Environment

This section uses Dockerfiles to configure Docker images. For more information about Dockerfile syntax and best practices, see our How To Use Dockerfiles guide and Docker’s Dockerfile Best Practices guide.

  1. Create a directory for the microservice:

    mkdir flask-microservice

  2. Create the directory structure for the microservice components within the new directory:

    cd flask-microservice
    mkdir nginx postgres web


NGINX

  1. Within the new nginx subdirectory, create a Dockerfile for the NGINX image:

    nginx/Dockerfile
    1
    2

    from nginx:alpine
    COPY nginx.conf /etc/nginx/nginx.conf
  2. Create the nginx.conf referenced in the Dockerfile:

    /nginx/nginx.conf
     1
     2
     3
     4
     5
     6
     7
     8
     9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37
    38
    39
    40

    user  nginx;
    worker_processes 1;
    error_log  /dev/stdout info;
    error_log off;
    pid        /var/run/nginx.pid;

    events {
        worker_connections  1024;
        use epoll;
        multi_accept on;
    }

    http {
        include       /etc/nginx/mime.types;
        default_type  application/octet-stream;

        log_format  main  '$remote_addr - $remote_user [$time_local] "$request" '
                          '$status $body_bytes_sent "$http_referer" '
                          '"$http_user_agent" "$http_x_forwarded_for"';

        access_log  /dev/stdout main;
        access_log off;
        keepalive_timeout 65;
        keepalive_requests 100000;
        tcp_nopush on;
        tcp_nodelay on;

        server {
            listen 80;
            proxy_pass_header Server;

            location / {
                proxy_set_header Host $host;
                proxy_set_header X-Real-IP $remote_addr;

                # app comes from /etc/hosts, Docker added it for us!
                proxy_pass http://flaskapp:8000/;
            }
        }
    }

PostgreSQL

The PostgreSQL image for this microservice will use the official postgresql image on Docker Hub, so no Dockerfile is necessary.

In the postgres subdirectory, create an init.sql file:

postgres/init.sql
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
SET statement_timeout = 0;
SET lock_timeout = 0;
SET idle_in_transaction_session_timeout = 0;
SET client_encoding = 'UTF8';
SET standard_conforming_strings = on;
SET check_function_bodies = false;
SET client_min_messages = warning;
SET row_security = off;
CREATE EXTENSION IF NOT EXISTS plpgsql WITH SCHEMA pg_catalog;
COMMENT ON EXTENSION plpgsql IS 'PL/pgSQL procedural language';
SET search_path = public, pg_catalog;
SET default_tablespace = '';
SET default_with_oids = false;
CREATE TABLE visitors (
    site_id integer,
    site_name text,
    visitor_count integer
);

ALTER TABLE visitors OWNER TO postgres;
COPY visitors (site_id, site_name, visitor_count) FROM stdin;
1 	linodeexample.com  	0
\.
Caution
In Line 22 of init.sql, make sure your text editor does not convert tabs to spaces. The app will not work without tabs between the entries in this line.

Web

The web image will hold an example Flask app. Add the following files to the web directory to prepare the app:

  1. Create a .python-version file to specify the use of Python 3.6:

    echo "3.6.0" >> web/.python-version

  2. Create a Dockerfile for the web image:

    web/Dockerfile
     1
     2
     3
     4
     5
     6
     7
     8
     9
    10

    from python:3.6.2-slim
    RUN groupadd flaskgroup && useradd -m -g flaskgroup -s /bin/bash flask
    RUN echo "flask ALL=(ALL) NOPASSWD:ALL" >> /etc/sudoers
    RUN mkdir -p /home/flask/app/web
    WORKDIR /home/flask/app/web
    COPY requirements.txt /home/flask/app/web
    RUN pip install --no-cache-dir -r requirements.txt
    RUN chown -R flask:flaskgroup /home/flask
    USER flask
    ENTRYPOINT ["/usr/local/bin/gunicorn", "--bind", ":8000", "linode:app", "--reload", "--workers", "16"]
  3. Create web/linode.py and add the example app script:

    web/linode.py
     1
     2
     3
     4
     5
     6
     7
     8
     9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37
    38
    39
    40
    41
    42
    43
    44
    45
    46
    47
    48
    49
    50
    51
    52
    53
    54
    55
    56
    57

    from flask import Flask
    import logging
    import psycopg2
    import redis
    import sys

    app = Flask(__name__)
    cache = redis.StrictRedis(host='redis', port=6379)

    # Configure Logging
    app.logger.addHandler(logging.StreamHandler(sys.stdout))
    app.logger.setLevel(logging.DEBUG)

    def PgFetch(query, method):

        # Connect to an existing database
        conn = psycopg2.connect("host='postgres' dbname='linode' user='postgres' password='linode123'")

        # Open a cursor to perform database operations
        cur = conn.cursor()

        # Query the database and obtain data as Python objects
        dbquery = cur.execute(query)

        if method == 'GET':
            result = cur.fetchone()
        else:
            result = ""

        # Make the changes to the database persistent
        conn.commit()

        # Close communication with the database
        cur.close()
        conn.close()
        return result

    @app.route('/')
    def hello_world():
        if cache.exists('visitor_count'):
            cache.incr('visitor_count')
            count = (cache.get('visitor_count')).decode('utf-8')
            update = PgFetch("UPDATE visitors set visitor_count = " + count + " where site_id = 1;", "POST")
        else:
            cache_refresh = PgFetch("SELECT visitor_count FROM visitors where site_id = 1;", "GET")
            count = int(cache_refresh[0])
            cache.set('visitor_count', count)
            cache.incr('visitor_count')
            count = (cache.get('visitor_count')).decode('utf-8')
        return 'Hello Linode!  This page has been viewed %s time(s).' % count

    @app.route('/resetcounter')
    def resetcounter():
        cache.delete('visitor_count')
        PgFetch("UPDATE visitors set visitor_count = 0 where site_id = 1;", "POST")
        app.logger.debug("reset visitor count")
        return "Successfully deleted redis and postgres counters"
  4. Add a requirements.txt file with the required Python dependencies:

    web/requirements.txt
    1
    2
    3
    4

    flask
    gunicorn
    psycopg2
    redis

Docker Compose

Docker Compose will be used to be define the connections between containers and their configuration settings.

Create a docker-compose.yml file in the flask-microservice directory and add the following:

docker-compose.yml
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
version: '3'
services:
 # Define the Flask web application
 flaskapp:

   # Build the Dockerfile that is in the web directory
   build: ./web

   # Always restart the container regardless of the exit status; try and restart the container indefinitely
   restart: always

   # Expose port 8000 to other containers (not to the host of the machine)
   expose:
     - "8000"

   # Mount the web directory within the container at /home/flask/app/web
   volumes:
     - ./web:/home/flask/app/web

   # Don't create this container until the redis and postgres containers (below) have been created
   depends_on:
     - redis
     - postgres

   # Link the redis and postgres containers together so that they can talk to one another
   links:
     - redis
     - postgres

   # Pass environment variables to the flask container (this debug level lets you see more useful information)
   environment:
     FLASK_DEBUG: 1

   # Deploy with 3 replicas in the case of failure of one of the containers (only in Docker Swarm)
   deploy:
     mode: replicated
     replicas: 3

 # Define the redis Docker container
 redis:

   # use the redis:alpine image: https://hub.docker.com/_/redis/
   image: redis:alpine
   restart: always
   deploy:
     mode: replicated
     replicas: 3

 # Define the redis NGINX forward proxy container
 nginx:

   # build the nginx Dockerfile: http://bit.ly/2kuYaIv
   build: nginx/
   restart: always

   # Expose port 80 to the host machine
   ports:
     - "80:80"
   deploy:
     mode: replicated
     replicas: 3

   # The Flask application needs to be available for NGINX to make successful proxy requests
   depends_on:
     - flaskapp

 # Define the postgres database
 postgres:
   restart: always
   # Use the postgres alpine image: https://hub.docker.com/_/postgres/
   image: postgres:alpine

   # Mount an initialization script and the persistent postgresql data volume
   volumes:
     - ./postgres/init.sql:/docker-entrypoint-initdb.d/init.sql
     - ./postgres/data:/var/lib/postgresql/data

   # Pass postgres environment variables
   environment:
     POSTGRES_PASSWORD: linode123
     POSTGRES_DB: linode

   # Expose port 5432 to other Docker containers
   expose:
     - "5432"

Test the Microservice

  1. Use Docker Compose to build all of the images and start the microservice:

    cd flask-microservice/ && docker-compose up


    You should see all of the services start in your terminal.

  2. Open a new terminal window and make a request to the example application:

    curl localhost



    Hello Linode! This page has been viewed 1 time(s).



  3. Reset the page hit counter:

    curl localhost/resetcounter


    Successfully deleted redis and postgres counters


  4. Return to the terminal window where Docker Compose was started to view the standard out log:


    flaskapp_1  | DEBUG in linode [/home/flask/app/web/linode.py:56]:
    flaskapp_1  | reset visitor count



Using Containers in Production: Best Practices

The containers used in the example microservice are intended to demonstrate the following best practices for using containers in production:

Containers should be:

  1. Ephemeral: It should be easy to stop, destroy, rebuild, and redeploy containers with minimal setup and configuration.

    The Flask microservice is an ideal example of this. The entire microservice can be brought up or down using Docker Compose. No additional configuration is necessary after the containers are running, which makes it easy to modify the application.

  2. Disposable: Ideally, any single container within a larger application should be able to fail without impacting the performance of the application. Using a restart: on-failure option in the docker-compose.yml file, as well as having a replica count, makes it possible for some containers in the example microservice to fail gracefully while still serving the web application with no degradation to the end user.

    Note
    The replica count directive will only be effective when this configuration is deployed as part of a Docker Swarm, which is not covered in this guide.
  3. Quick to start: Avoiding additional installation steps in the Docker file, removing dependencies that aren’t needed, and building a target image that can be reused are three of the most important steps in making a web application that has a quick initialization time within Docker. The example application uses short, concise, prebuilt Dockerfiles in order to minimize initialization time.

  4. Quick to stop: Validate that a docker kill --signal=SIGINT {APPNAME} stops the application gracefully. This, along with a restart condition and a replica condition, will ensure that when containers fail, they will be brought back online efficiently.

  5. Lightweight: Use the smallest base container that provides all of the utilities that are needed to build and run your application. Many Docker images are based on Alpine Linux, a light and simple Linux distribution that takes up only 5MB in a Docker image. Using a small distro saves network and operational overhead and greatly increases container performance. The example application uses alpine images where applicable (NGINX, Redis, and PostgreSQL), and uses a python-slim base image for the Gunicorn / Flask application.

  6. Stateless: Since they are ephemeral, containers typically shouldn’t maintain state. An application’s state should be stored in a separate, persistent data volume, as is the case with the microservice’s PostgreSQL data store. The Redis key-value store does maintain data within a container, but this data is not application-critical; the Redis store will fail back gracefully to the database should the container not be able to respond.

  7. Portable: All of an app’s dependencies that are needed for the container runtime should be locally available. All of the example microservice’s dependencies and startup scripts are stored in the directory for each component. These can be checked into version control, making it easy to share and deploy the application.

  8. Modular: Each container should have one responsibility and one process. In this microservice, each of the major processes (NGINX, Python, Redis, and PostgreSQL) is deployed in a separate container.

  9. Logging: All containers should log to STDOUT. This uniformity makes it easy to view the logs for all of the processes in a single stream.

  10. Resilient: The example application restarts its containers if they are exited for any reason. This helps give your Dockerized application high availability and performance, even during maintenance periods.

More Information

You may wish to consult the following resources for additional information on this topic. While these are provided in the hope that they will be useful, please note that we cannot vouch for the accuracy or timeliness of externally hosted materials.

Join our Community

Find answers, ask questions, and help others.

comments powered by Disqus

This guide is published under a CC BY-ND 4.0 license.
