Build NGINX with PageSpeed From Source

Updated , by Linode

Traducciones al Español
Estamos traduciendo nuestros guías y tutoriales al Español. Es posible que usted esté viendo una traducción generada automáticamente. Estamos trabajando con traductores profesionales para verificar las traducciones de nuestro sitio web. Este proyecto es un trabajo en curso.

Build NGINX with PageSpeed From Source

What is Google PageSpeed?

PageSpeed is a set of modules for NGINX and Apache which optimize and measure page performance of websites. Optimization is done by minifying static assets such as CSS and JavaScript, which decreases page load time. PageSpeed Insights is a tool that measures your site’s performance, and makes recommendations for further modifications based on the results.

There are currently two ways to get PageSpeed and NGINX working together:

  • Compile NGINX with support for PageSpeed, then compile PageSpeed.

  • Compile PageSpeed as a dynamic module to use with NGINX, whether NGINX was installed from source or a binary.

    Installing NGINX from source requires several manual installation steps and will require manual maintenance when performing tasks like version upgrades. To install NGINX using a package manager see the NGINX section.

This guide will show how to compile both NGINX and PageSpeed. If you would prefer to use PageSpeed as a module for NGINX, see this NGINX blog post for instructions.

Before You Begin

  • You should not have a pre-existing installation of NGINX. If you do, back up the configuration files if you want to retain their information, and then purge NGINX.

  • You will need root access to the system, or a user account with sudo privileges.

  • Set your system’s hostname.

  • Update your system’s packages.

Considerations for a Self-Compiled NGINX Installation

Filesystem Locations: When you compile NGINX from source, the entire installation, including configuration files, is located at /usr/local/nginx/nginx/. This is in contrast to an installation from a package manager, which places its configuration files in /etc/nginx/.

Built-in Modules: When you compile NGINX from source, no additional modules are included unless explicitly specified, which means that HTTPS is not supported by default. Below you can see the output of nginx -V using the PageSpeed automated install command on Ubuntu 18.04 with no additional modules or options specified.

[email protected]:~# /usr/local/nginx/sbin/nginx -V
nginx version: nginx/1.17.3
built by gcc 7.4.0 (Ubuntu 7.4.0-1ubuntu1~18.04.1)
configure arguments: --add-module=/root/incubator-pagespeed-ngx-latest-stable

Contrast this output with the same command run on the same Ubuntu system but with the binary installed from NGINX’s repository:

[email protected]:~# nginx -V
nginx version: nginx/1.17.3
built by gcc 7.4.0 (Ubuntu 7.4.0-1ubuntu1~18.04.1)
built with OpenSSL 1.1.1  11 Sep 2018
TLS SNI support enabled
configure arguments: --add-module=/root/incubator-pagespeed-ngx-latest-stable --prefix=/etc/nginx --sbin-path=/usr/sbin/nginx --modules-path=/usr/lib/nginx/modules --conf-path=/etc/nginx/nginx.conf --error-log-path=/var/log/nginx/error.log --http-log-path=/var/log/nginx/access.log --pid-path=/var/run/ --lock-path=/var/run/nginx.lock --http-client-body-temp-path=/var/cache/nginx/client_temp --http-proxy-temp-path=/var/cache/nginx/proxy_temp --http-fastcgi-temp-path=/var/cache/nginx/fastcgi_temp --http-uwsgi-temp-path=/var/cache/nginx/uwsgi_temp --http-scgi-temp-path=/var/cache/nginx/scgi_temp --user=nginx --group=nginx --with-http_ssl_module --with-http_v2_module

Build NGINX and PageSpeed

The official PageSpeed documentation provides a bash script to automate the installation process.

The automated installation script will install several compilation tools needed to install PageSpeed. If you are using a production environment, ensure you uninstall any packages that are no longer needed after the installation has completed.
  1. If you plan to serve your website using TLS, install the SSL libraries needed to compile the HTTPS module for NGINX:


    sudo yum install openssl-devel


    sudo apt install libssl-dev
  2. Run the Automated Install bash command to start the installation:

    bash <(curl -f -L -sS \
    --nginx-version latest
  3. During the build process, you’ll be asked if you want to build NGINX with any additional modules. The PageSpeed module is already included, so you don’t need to add it here.

    The options below are a recommended starting point; you can also add more specialized options for your particular use case. These options retain the directory paths, user and group names of pre-built NGINX binaries, and enable the SSL and HTTP/2 modules for HTTPS connections:

    --prefix=/etc/nginx --sbin-path=/usr/sbin/nginx --modules-path=/usr/lib/nginx/modules --conf-path=/etc/nginx/nginx.conf --error-log-path=/var/log/nginx/error.log --http-log-path=/var/log/nginx/access.log --pid-path=/var/run/ --lock-path=/var/run/nginx.lock --http-client-body-temp-path=/var/cache/nginx/client_temp --http-proxy-temp-path=/var/cache/nginx/proxy_temp --http-fastcgi-temp-path=/var/cache/nginx/fastcgi_temp --http-uwsgi-temp-path=/var/cache/nginx/uwsgi_temp --http-scgi-temp-path=/var/cache/nginx/scgi_temp --user=nginx --group=nginx --with-http_ssl_module --with-http_v2_module
  4. You’ll be asked if you want to configure nginx with the options that you added, answer Y to continue.

    ./configure --add-module=/home/sudouser/incubator-pagespeed-ngx-latest-stable --prefix=/etc/nginx --sbin-path=/usr/sbin/nginx --modules-path=/usr/lib/nginx/modules --conf-path=/etc/nginx/nginx.conf --error-log-path=/var/log/nginx/error.log --http-log-path=/var/log/nginx/access.log --pid-path=/var/run/ --lock-path=/var/run/nginx.lock --http-client-body-temp-path=/var/cache/nginx/client_temp --http-proxy-temp-path=/var/cache/nginx/proxy_temp --http-fastcgi-temp-path=/var/cache/nginx/fastcgi_temp --http-uwsgi-temp-path=/var/cache/nginx/uwsgi_temp --http-scgi-temp-path=/var/cache/nginx/scgi_temp --user=nginx --group=nginx --with-http_ssl_module --with-http_v2_module
    Does this look right? [Y/n] y

  5. Next you’ll be asked if you want to build NGINX. You’ll be shown the destination directories for logs, configuration files and binaries. If these look correct, answer Y to continue.

    Configuration summary
      + using system PCRE library
      + using system OpenSSL library
      + using system zlib library
      nginx path prefix: "/etc/nginx"
      nginx binary file: "/usr/sbin/nginx"
      nginx modules path: "/usr/lib/nginx/modules"
      nginx configuration prefix: "/etc/nginx"
      nginx configuration file: "/etc/nginx/nginx.conf"
      nginx pid file: "/var/run/"
      nginx error log file: "/var/log/nginx/error.log"
      nginx http access log file: "/var/log/nginx/access.log"
      nginx http client request body temporary files: "/var/cache/nginx/client_temp"
      nginx http proxy temporary files: "/var/cache/nginx/proxy_temp"
      nginx http fastcgi temporary files: "/var/cache/nginx/fastcgi_temp"
      nginx http uwsgi temporary files: "/var/cache/nginx/uwsgi_temp"
      nginx http scgi temporary files: "/var/cache/nginx/scgi_temp"
    Build nginx? [Y/n]
  6. If the build was successful, you’ll see the following message:

    Nginx installed with ngx_pagespeed support compiled-in.
    If this is a new installation you probably need an init script to
    manage starting and stopping the nginx service.  See:
    You'll also need to configure ngx_pagespeed if you haven't yet:
  7. When you want to update NGINX, back up your configuration files and repeat steps two through four above to build with the new source version.

Control NGINX

NGINX can be controlled either by creating a systemd service or by calling the binary directly. Choose one of these methods and do not mix them. If you start NGINX using the binary commands, for example, systemd will not be aware of the process and will try to start another NGINX instance if you run systemctl start nginx, which will fail.


  1. In a text editor, create /lib/systemd/system/nginx.service and add the following unit file from the NGINX wiki:

    File: /lib/systemd/system/nginx.service
    Description=The NGINX HTTP and reverse proxy server
    ExecStartPre=/usr/sbin/nginx -t
    ExecReload=/bin/kill -s HUP $MAINPID
    ExecStop=/bin/kill -s QUIT $MAINPID
  2. Enable NGINX to start on boot and start the server:

    systemctl enable nginx
    systemctl start nginx
  3. NGINX can now be controlled as with any other systemd-controlled process:

    systemctl stop nginx
    systemctl restart nginx
    systemctl status nginx

NGINX binary

You can use NGINX’s binary to control the process directly without making a startup file for your init system.

  1. Start NGINX:

  2. Reload the configuration:

    /usr/sbin/nginx -s reload
  3. Stop NGINX:

    /usr/sbin/nginx -s stop



  1. Since the compiled options specified above are different than the source’s defaults, some additional configuration is necessary. Replace in the following commands with your Linode’s public IP address or domain name:

    sudo useradd --no-create-home nginx
    sudo mkdir -p /var/cache/nginx/client_temp
    sudo mkdir /etc/nginx/conf.d/
    sudo mkdir /var/www/
    sudo mkdir /var/www/
    sudo chown nginx:nginx /var/www/
    sudo mv /etc/nginx/nginx.conf.default /etc/nginx/nginx.conf.backup-default
  2. In NGINX terminology, a Server Block equates to a website (similar to the Virtual Host in Apache terminology). Each NGINX site’s configuration should be in its own file with the name formatted as, located at /etc/nginx/conf.d/.

    If you followed this guide or our Getting Started with NGINX series, then your site’s configuration will be in a server block in a file stored in /etc/nginx/conf.d/. If you do not have this setup, then you likely have the server block directly in /etc/nginx/nginx.conf. See Server Block Examples in the NGINX docs for more info.

    Create a configuration file for your site with a basic server block inside:

    File: /etc/nginx/conf.d/
    server {
        listen       80;
        listen       [::]:80;
        access_log   logs/example.access.log main;
        error_log    logs/example.error error;
        root         /var/www/;
  3. Ensure that the firewall allows access to the nginx service. If you configured the firewall with ufw then do the following:

    a. Check the application configurations that ufw is aware of, by typing:

     sudo ufw app list

    b. Enable Nginx HTTP from the list:

     sudo ufw allow 'Nginx HTTP'

    c. Verify the change by typing:

    Status: active
    To                         Action      From
    --                         ------      ----
    OpenSSH                    ALLOW       Anywhere
    Nginx HTTP                 ALLOW       Anywhere
    OpenSSH (v6)               ALLOW       Anywhere (v6)
    Nginx HTTP (v6)            ALLOW       Anywhere (v6)

  4. Start NGINX:


    systemctl start nginx

    Other init systems:

  5. Verify NGINX is working by going to your site’s domain or IP address in a web browser. You should see the NGINX welcome page:

    NGINX welcome page


  1. Create PageSpeed’s cache location and change its ownership to the nginx user and group:

    sudo mkdir /var/cache/ngx_pagespeed/
    sudo chown nginx:nginx /var/cache/ngx_pagespeed/
  2. Add the PageSpeed directives to your site configuration’s server block as shown below.

    File: /etc/nginx/conf.d/
    server {
        pagespeed on;
        pagespeed FileCachePath "/var/cache/ngx_pagespeed/";
        pagespeed RewriteLevel OptimizeForBandwidth;
        location ~ "\.pagespeed\.([a-z]\.)?[a-z]{2}\.[^.]{10}\.[^.]+" {
            add_header "" "";
        location ~ "^/pagespeed_static/" { }
        location ~ "^/ngx_pagespeed_beacon$" { }
    RewriteLevel OptimizeForBandwidth is a safer choice than the default CoreFilters rewrite level.
  3. NGINX supports HTTPS by default, so if your site already is set up with a TLS certificate, add the two directives below to your site’s server block, pointing to the correct location depending on your system.

    pagespeed SslCertDirectory directory;
    pagespeed SslCertFile file;
  4. Reload your configuration:

    /usr/sbin/nginx/ -s reload

    Or restart nginx:

    systemctl restart nginx
  5. Test PageSpeed is running and NGINX is successfully serving pages. Substitute in the cURL command with your Linode’s domain name or IP address.

    curl -I -X GET

    The output should be similar to below. If the response contains an HTTP 200 response and X-Page-Speed is listed in the header with the PageSpeed version number, everything is working correctly.

    HTTP/1.1 200 OK
    Server: nginx/1.17.3
    Content-Type: text/html
    Transfer-Encoding: chunked
    Connection: keep-alive
    Date: Sat, 07 Sep 2019 07:16:44 GMT
    Cache-Control: max-age=0, no-cache
  6. Use PageSpeed Insights to test your site for additional improvement areas.
