The Postfix Mail Transfer Agent (MTA) is a high performance open source e-mail server system. This guide will help you get Postfix running on your CentOS 6 Linode, using Dovecot for IMAP/POP3 service, and MySQL to store information on virtual domains and users.

Email restrictions on the Linode Platform
In an effort to fight spam originating from our platform, outbound connections on ports 25, 465, and 587 are blocked by default on Compute Instances for some new accounts. These restrictions prevent applications from sending email. If you intend to send email from a Compute Instance, review the Send Email on the Linode Platform guide to learn more about our email policies and to request the removal of these restrictions.

Before You Begin

Prior to using this guide, be sure you have followed the Setting Up and Securing a Compute Instance and set your hostname.

Note
The steps in this guide require root privileges. Be sure to run the steps below as root, or use su - root to log in as root. Certain commands below cannot be run as sudo and must be run as root.

Install Required Packages

  1. Install any outstanding package updates:

    yum update

  2. The version of Postfix included in the main CentOS repository does not include support for MySQL; therefore, you will need install Postfix from the CentOS Plus repository. Before doing so, add exclusions to the [base] and [updates] repositories for the Postfix package to prevent it from being overwritten with updates that do not have MySQL support:

    File: /etc/yum.repos.d/CentOS-Base.repo
    1
    2
    3
    4
    5
    6
    7
    8

    [base]
    name=CentOS-$releasever - Base
    exclude=postfix

    # released updates
    [updates]
    name=CentOS-$releasever - Updates
    exclude=postfix
  3. Install the required packages:

    yum --enablerepo=centosplus install postfix
    yum install dovecot mysql-server dovecot-mysql


    This installs the Postfix mail server, the MySQL database server, the Dovecot IMAP and POP daemons, and several supporting packages that provide services related to authentication.

Next, set up a MySQL database to handle virtual domains and users.

Set up MySQL for Virtual Domains and Users

  1. Configure MySQL to start on boot, then start MySQL:

    chkconfig mysqld on
    service mysqld start

  2. Run mysql_secure_installation. You will be presented with the opportunity to change the MySQL root password, remove anonymous user accounts, disable root logins outside of localhost, remove test databases, and reload privilege tables. It is recommended that you answer yes to these options:

    mysql_secure_installation

  3. Start the MySQL shell:

    mysql -u root -p

  4. Create a database for your mail server and switch to it:

    CREATE DATABASE mail;
    USE mail;

  5. Create a mail administration user called mail_admin and grant it permissions on the mail database. Please be sure to replace mail_admin_password with a strong password:

    GRANT SELECT, INSERT, UPDATE, DELETE ON mail.* TO 'mail_admin'@'localhost' IDENTIFIED BY 'mail_admin_password';
    GRANT SELECT, INSERT, UPDATE, DELETE ON mail.* TO 'mail_admin'@'localhost.localdomain' IDENTIFIED BY 'mail_admin_password';
    FLUSH PRIVILEGES;

  6. Create the virtual domains table:

    CREATE TABLE domains (domain varchar(50) NOT NULL, PRIMARY KEY (domain) );

  7. Create a table to handle mail forwarding:

    CREATE TABLE forwardings (source varchar(80) NOT NULL, destination TEXT NOT NULL, PRIMARY KEY (source) );

  8. Create the users table:

    CREATE TABLE users (email varchar(80) NOT NULL, password varchar(20) NOT NULL, PRIMARY KEY (email) );

  9. Create a transports table:

    CREATE TABLE transport ( domain varchar(128) NOT NULL default '', transport varchar(128) NOT NULL default '', UNIQUE KEY domain (domain) );

  10. Exit the MySQL shell:

    quit

  11. Bind MySQL to localhost (127.0.0.1) by editing /etc/my.cnf, and adding the following to the [mysqld] section of the file:

    File: /etc/my.cnf
    1

    bind-address=127.0.0.1

    This is required for Postfix to be able to communicate with the database server. If you have MySQL set up to listen on another IP address (such as an internal IP), you will need to substitute this IP address in place of 127.0.0.1 during the Postfix configuration steps. It is not advisable to run MySQL on a publicly-accessible IP address.

  12. Restart the database server:

    service mysqld restart


Next, perform additional Postfix configuration to set up communication with the database.

Configure Postfix to work with MySQL

Note
For the next four steps, replace mail_admin_password with the mail_admin password input earlier.
  1. Create a virtual domain configuration file for Postfix called /etc/postfix/mysql-virtual_domains.cf:

    File: /etc/postfix/mysql-virtual_domains.cf
    1
    2
    3
    4
    5

    user = mail_admin
    password = mail_admin_password
    dbname = mail
    query = SELECT domain AS virtual FROM domains WHERE domain='%s'
    hosts = 127.0.0.1
  2. Create a virtual forwarding file for Postfix called /etc/postfix/mysql-virtual_forwardings.cf:

    File: /etc/postfix/mysql-virtual_forwardings.cf
    1
    2
    3
    4
    5

    user = mail_admin
    password = mail_admin_password
    dbname = mail
    query = SELECT destination FROM forwardings WHERE source='%s'
    hosts = 127.0.0.1
  3. Create a virtual mailbox configuration file for Postfix called /etc/postfix/mysql-virtual_mailboxes.cf:

    File: /etc/postfix/mysql-virtual_mailboxes.cf
    1
    2
    3
    4
    5

    user = mail_admin
    password = mail_admin_password
    dbname = mail
    query = SELECT CONCAT(SUBSTRING_INDEX(email,<'@'>,-1),'/',SUBSTRING_INDEX(email,<'@'>,1),'/') FROM users WHERE email='%s'
    hosts = 127.0.0.1
  4. Create a virtual email mapping file for Postfix called /etc/postfix/mysql-virtual_email2email.cf:

    File: /etc/postfix/mysql-virtual_email2email.cf
    1
    2
    3
    4
    5

    user = mail_admin
    password = mail_admin_password
    dbname = mail
    query = SELECT email FROM users WHERE email='%s'
    hosts = 127.0.0.1
  5. Set proper permissions and ownership for these configuration files:

    chmod o= /etc/postfix/mysql-virtual_*.cf
    chgrp postfix /etc/postfix/mysql-virtual_*.cf

  6. Create a user and group for mail handling. All virtual mailboxes will be stored under this user’s home directory:

    groupadd -g 5000 vmail
    useradd -g vmail -u 5000 vmail -d /home/vmail -m

  7. Complete the remaining steps required for Postfix configuration. Please be sure to replace server.example.com with the Linode’s fully qualified domain name. If you are planning on using your own SSL certificate and key, replace /etc/pki/dovecot/private/dovecot.pem with the appropriate path:

    postconf -e 'myhostname = server.example.com'
    postconf -e 'mydestination = $myhostname, localhost, localhost.localdomain'
    postconf -e 'mynetworks = 127.0.0.0/8'
    postconf -e 'inet_interfaces = all'
    postconf -e 'message_size_limit = 30720000'
    postconf -e 'virtual_alias_domains ='
    postconf -e 'virtual_alias_maps = proxy:mysql:/etc/postfix/mysql-virtual_forwardings.cf, mysql:/etc/postfix/mysql-virtual_email2email.cf'
    postconf -e 'virtual_mailbox_domains = proxy:mysql:/etc/postfix/mysql-virtual_domains.cf'
    postconf -e 'virtual_mailbox_maps = proxy:mysql:/etc/postfix/mysql-virtual_mailboxes.cf'
    postconf -e 'virtual_mailbox_base = /home/vmail'
    postconf -e 'virtual_uid_maps = static:5000'
    postconf -e 'virtual_gid_maps = static:5000'
    postconf -e 'smtpd_sasl_type = dovecot'
    postconf -e 'smtpd_sasl_path = private/auth'
    postconf -e 'smtpd_sasl_auth_enable = yes'
    postconf -e 'broken_sasl_auth_clients = yes'
    postconf -e 'smtpd_sasl_authenticated_header = yes'
    postconf -e 'smtpd_recipient_restrictions = permit_mynetworks, permit_sasl_authenticated, reject_unauth_destination'
    postconf -e 'smtpd_use_tls = yes'
    postconf -e 'smtpd_tls_cert_file = </etc/pki/dovecot/certs/dovecot.pem'
    postconf -e 'smtpd_tls_key_file = </etc/pki/dovecot/private/dovecot.pem'
    postconf -e 'virtual_create_maildirsize = yes'
    postconf -e 'virtual_maildir_extended = yes'
    postconf -e 'proxy_read_maps = $local_recipient_maps $mydestination $virtual_alias_maps $virtual_alias_domains $virtual_mailbox_maps $virtual_mailbox_domains $relay_recipient_maps $relay_domains $canonical_maps $sender_canonical_maps $recipient_canonical_maps $relocated_maps $transport_maps $mynetworks $virtual_mailbox_limit_maps'
    postconf -e 'virtual_transport = dovecot'
    postconf -e 'dovecot_destination_recipient_limit = 1'

  8. Edit the file /etc/postfix/master.cf and add the Dovecot service to the bottom of the file:

    File: /etc/postfix/master.cf
    1
    2

    dovecot   unix  -       n       n       -       -       pipe
        flags=DRhu user=vmail:vmail argv=/usr/libexec/dovecot/deliver -f ${sender} -d ${recipient}
  9. Configure Postfix to start on boot and start the service for the first time:

    chkconfig postfix on
    service postfix start


This completes the configuration for Postfix.

Configure Dovecot

  1. Move /etc/dovecot/dovecot.conf to a backup file:

    mv /etc/dovecot/dovecot.conf /etc/dovecot/dovecot.conf-backup

  2. Copy the following into the now-empty dovecot.conf file, substituting your system’s domain name for example.com in line 37:

    File: /etc/dovecot/dovecot.conf
     1
     2
     3
     4
     5
     6
     7
     8
     9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37
    38
    39
    40
    41
    42
    43
    44
    45
    46
    47
    48
    49
    50
    51
    52

    protocols = imap pop3
    log_timestamp = "%Y-%m-%d %H:%M:%S "
    mail_location = maildir:/home/vmail/%d/%n/Maildir

    ssl_cert = </etc/pki/dovecot/certs/dovecot.pem
    ssl_key = </etc/pki/dovecot/private/dovecot.pem

    namespace {
        type = private
        separator = .
        prefix = INBOX.
        inbox = yes
    }

    service auth {
        unix_listener auth-master {
            mode = 0600
            user = vmail
        }

        unix_listener /var/spool/postfix/private/auth {
            mode = 0666
            user = postfix
            group = postfix
        }

    user = root
    }

    service auth-worker {
        user = root
    }

    protocol lda {
        log_path = /home/vmail/dovecot-deliver.log
        auth_socket_path = /var/run/dovecot/auth-master
        postmaster_address = postmaster@example.com
    }

    protocol pop3 {
        pop3_uidl_format = %08Xu%08Xv
    }

    passdb {
        driver = sql
        args = /etc/dovecot/dovecot-sql.conf.ext
    }

    userdb {
        driver = static
        args = uid=5000 gid=5000 home=/home/vmail/%d/%n allow_all_users=yes
    }
  3. MySQL will be used to store password information, so /etc/dovecot/dovecot-sql.conf.ext must be created. Insert the following contents into the file, making sure to replace mail_admin_password with your mail password:

    File: /etc/dovecot/dovecot-sql.conf.ext
    1
    2
    3
    4

    driver = mysql
    connect = host=127.0.0.1 dbname=mail user=mail_admin password=mail_admin_password
    default_pass_scheme = CRYPT
    password_query = SELECT email as user, password FROM users WHERE email='%u';
  4. Restrict access to the file by changing the permissions to allow users in the dovecot group to access it, while denying access to others:

    chgrp dovecot /etc/dovecot/dovecot-sql.conf.ext
    chmod o= /etc/dovecot/dovecot-sql.conf.ext

  5. Configure Dovecot to start on boot, and start it for the first time:

    chkconfig dovecot on
    service dovecot start

  6. Check /var/log/maillog to make sure Dovecot started without errors. Your log should have lines similar to the following:

    File: /var/log/maillog
    1
    2
    3

    Mar 18 15:21:59 sothoryos postfix/postfix-script[3069]: starting the Postfix mail system
    Mar 18 15:22:00 sothoryos postfix/master[3070]: daemon started -- version 2.6.6, configuration /etc/postfix
    Mar 18 15:32:03 sothoryos dovecot: master: Dovecot v2.0.9 starting up (core dumps disabled)
  7. Test your POP3 server to make sure it’s running properly:

    yum install telnet
    telnet localhost pop3

  8. The terminal should output results similar to the following:

    Trying 127.0.0.1...
    Connected to localhost.localdomain.
    Escape character is '^]'.
    +OK Dovecot ready.

  9. Enter the command quit to return to your shell. This completes the Dovecot configuration. Next, you’ll make sure aliases are configured properly.

Configure Mail Aliases

  1. Edit the file /etc/aliases, making sure the postmaster and root directives are set properly for your organization:

    File: /etc/aliases
    1
    2

    postmaster: root
    root: postmaster@example.com
  2. Update aliases and restart Postfix:

    newaliases
    service postfix restart


This completes alias configuration. Next, test Postfix to make sure it’s operating properly.

Testing Postfix

  1. Test Postfix for SMTP-AUTH and TLS:

    telnet localhost 25

  2. While still connected, issue the following command:

    ehlo localhost

  3. You should see output similar to the following:

    250-hostname.example.com
    250-PIPELINING
    250-SIZE 30720000
    250-VRFY
    250-ETRN
    250-STARTTLS
    250-AUTH PLAIN
    250-AUTH=PLAIN
    250-ENHANCEDSTATUSCODES
    250-8BITMIME
    250 DSN

  4. Issue the command quit to terminate the telnet connection.

Next, populate the MySQL database with domains and email users.

Set Up and Test Domains and Users

Note
Before continuing, modify the DNS records for any domains that you wish to handle email by adding an MX record that points to your mail server’s fully qualified domain name. If MX records already exist for a domain you would like to handle the email for, either delete them or set them to a higher priority number than your mail server. Smaller priority numbers indicate higher priority for mail delivery, with “0” being the highest priority.

In the following example, the MySQL shell is used to add support for the domain “example.com”, which will have an email account called “sales”.

  1. Log into the MySQL shell:

    mysql -u root -p

  2. Switch to the mail database, add support for your domain, and create an email account. Be sure to replace example.com with your domain name, sales@example.com with your chosen email, and password with a strong password:

    USE mail;
    INSERT INTO domains (domain) VALUES ('example.com');
    INSERT INTO users (email, password) VALUES ('sales@example.com', ENCRYPT('password'));
    quit

  3. Prior to accessing any newly-created email account, a test message needs to be sent to create that user’s mailbox:

    yum install mailx
    mailx sales@example.com


    Press Ctrl+D to complete the message. You can safely leave the field for Cc: blank. This completes the configuration for a new domain and email user.

Note
Given the possibility for virtual hosting a large number of domains on a single mail system, the username portion of an email address (i.e. before the @ sign) is not sufficient for authentication. When email users authenticate to the server, they must supply the entire email address created above as their username.

Check Your Logs

After the test mail is sent, check the mail logs to make sure the mail was delivered.

  1. Check the maillog located in /var/log/maillog. You should see something similar to the following:

    File: /var/log/maillog
    1
    2
    3
    4

    Mar 18 15:39:07 server postfix/cleanup[3252]: 444E34055: message-id=<20150318153907.444E34055@server.example.com>
    Mar 18 15:39:07 server postfix/qmgr[3218]: 444E34055: from=<root@server.example.com>, size=489, nrcpt=1 (queue active)
    Mar 18 15:39:07 server postfix/pipe[3258]: 444E34055: to=<sales@example.com>, relay=dovecot, delay=0.09, delays=0.04/0.01/0/0.05, dsn=2.0.0, sta$
    Mar 18 15:39:07 server postfix/qmgr[3218]: 444E34055: removed
  2. Check the Dovecot delivery log located in /home/vmail/dovecot-deliver.log. The contents should look similar to the following:

    File: /home/vmail/dovecot-deliver.log
    1

    deliver(<sales@example.com>): 2011-01-21 20:03:19 Info: msgid=\<<20110121200319.E1D148908@hostname.example.com>>: saved mail to INBOX

Now you can test to see what the users of your email server would see with their email clients.

Test the Mailbox

  1. To test the sales@example.com mailbox, navigate to the mailbox directory /home/vmail/example.com/sales/Maildir and issue the following command:

    cd /home/vmail/example.com/sales/Maildir
    find

  2. You should see output similar to the following:

    .
    ./dovecot-uidlist
    ./cur
    ./new
    ./new/1285609582.P6115Q0M368794.li172-137
    ./dovecot.index
    ./dovecot.index.log
    ./tmp

  3. Test the mailbox by using a mail client. For this test, using mutt is recommended. If it is not installed by default, install it with yum install mutt, then run:

    mutt -f .


    You may be prompted to create the root mailbox. This is not required.

  4. If there is an email in the inbox, Postfix, Dovecot, and MySQL have been successfully configured! To quit mutt press q.

    Your mailbox is working!

More Information

You may wish to consult the following resources for additional information on this topic. While these are provided in the hope that they will be useful, please note that we cannot vouch for the accuracy or timeliness of externally hosted materials.

This page was originally published on


Your Feedback Is Important

Let us know if this guide was helpful to you.


Join the conversation.
Read other comments or post your own below. Comments must be respectful, constructive, and relevant to the topic of the guide. Do not post external links or advertisements. Before posting, consider if your comment would be better addressed by contacting our Support team or asking on our Community Site.
The Disqus commenting system for Linode Docs requires the acceptance of Functional Cookies, which allow us to analyze site usage so we can measure and improve performance. To view and create comments for this article, please update your Cookie Preferences on this website and refresh this web page. Please note: You must have JavaScript enabled in your browser.
