Getting Started with NGINX (Part 4): TLS Deployment Best Practices
Traducciones al EspañolEstamos traduciendo nuestros guías y tutoriales al Español. Es posible que usted esté viendo una traducción generada automáticamente. Estamos trabajando con traductores profesionales para verificar las traducciones de nuestro sitio web. Este proyecto es un trabajo en curso.
![](/docs/images/pix.gif)
![TLS Deployment Best Practices TLS Deployment Best Practices](/docs/guides/getting-started-with-nginx-part-4-tls-deployment-best-practices/_hu2d51a90a29b3ef77a1c314b6f9056a6a_49163_860ea0e8ffe120a7012c92a55a7c98aa.jpg)
![TLS Deployment Best Practices TLS Deployment Best Practices](/docs/guides/getting-started-with-nginx-part-4-tls-deployment-best-practices/_hu2d51a90a29b3ef77a1c314b6f9056a6a_49163_462965897cc1d402c207a76a50e9e868.jpg)
Before you Begin
This guide is Part 4 of our Getting Started with NGINX series and you will need a working NGINX setup with a website accessible via HTTPS. If do not already have that, then complete at least Part 1: Basic Installation and Setup and Part 3: Enable TLS on NGINX for HTTPS Connections before going further.
You will need root access to the system, or a user account with
sudo
privilege.You may want to make another backup of your
nginx.conf
and site configuration files so you have a snapshot of the work you’ve done up to this point. The copy commands below are intended as quick examples. By now you’ve likely put a significant amount of work into this setup, so you should decide on a more resilient backup strategy to preserve your configuration and site data.cp /etc/nginx/nginx.conf /etc/nginx/nginx.conf.backup-pt4 cp -r /etc/nginx/conf.d/ /etc/nginx/conf.d-backup-pt4
To enable any configuration changes you make, you need to run
nginx -s reload
as root.Important Most directives in this guide can be added either to NGINX’shttp
block, or an individual site’sserver
block. The exceptions areadd_header
directives, which are not inherited. If you’re only hosting one website, or if you want all your hosted sites to have the same NGINX parameters, then adding all youradd_header
directives thehttp
block is fine. If you intend to use different header options for different site configurations, see here for a different approach.
Redirect Incoming HTTP Traffic HTTPS
When someone types your website’s domain into a browser, the usual behavior is that the site is loaded over HTTP, unencrypted. Redirecting HTTP requests to HTTPS means that a person can still type your site name into their browser’s address bar without specifying https://
, but NGINX will redirect their browser to your site using an HTTPS connection.
Search engine results rank HTTPS-capable websites higher than sites available only over HTTP, so redirecting HTTP requests to HTTPS is also useful to help increase your page rank.
Assuming you already have a working HTTPS connection with a site configuration file similar to the SSL
server
block below (the second one), add the HTTPserver
block (the first one) above it as shown:- File: /etc/nginx/conf.d/example.com.conf
1 2 3 4 5 6 7 8 9 10 11 12
server { listen 80; server_name example.com www.example.com; return 301 https://example.com$request_uri; } server { listen 443 ssl default_server; listen [::]:443 ssl default_server ; server_name example.com www.example.com; root /var/www/example.com; }
The return directives will be what handles the redirects. Whether to include directives for both
example.com
orwww.example.com
, depends on which domain your certificate was issued for, if not both. (The NGINX docs explain why you should usereturn 301
instead ofrewrite
).Reload NGINX:
nginx -s reload
Go to your site’s domain or IP address in a web browser, specifying
http://
. You should be redirected to HTTPS.
HTTP Strict Transport Security (HSTS)
HSTS is used to force browsers to only connect using HTTPS, but is a different concept from the return redirect method above. Some things to bear in mind if you’re considering enabling HSTS:
- Your site will be inaccessible over HTTP.
- Your site will inaccessible if using a self-signed certificate certificate, or if your commercially signed certificate expires.
- Web browsers won’t let users bypass any certificate warnings unless your HSTS header expires or their browser cache is cleared.
For more information on HSTS in NGINX, see NGINX’s blog.
Add the HSTS header directive to the
http
block of/etc/nginx/nginx.conf
. If you choose to put it elsewhere, remember that HTTP response header fields are not inherited from parent blocks.- File: /etc/nginx/nginx.conf
1
add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;
Reload NGINX:
nginx -s reload
Test that HSTS is working with:
curl -s -D- https://example.com | grep Strict
The output should be:
Strict-Transport-Security: max-age=31536000; includeSubDomains
Create a Larger Diffie-Hellman Prime
A Diffie-Hellman parameter is a set of randomly generated data used when establishing Perfect Forward Secrecy during initiation of an HTTPS connection. The default size is usually 1024 or 2048 bits, depending on the server’s OpenSSL version, but a 4096 bit key will provide greater security.
Change directories to where you maintain your site’s TLS certificates. From Part 3, we’re maintaining the server’s certificates out of
/root/certs/example.com/
so we’ll continue with that here.cd /root/certs/example.com
Create a 4096 bit Diffie-Hellman prime. Depending on the size of your Linode, this could take about 10 minutes to complete.
openssl genpkey -genparam -algorithm DH -out /root/certs/example.com/dhparam4096.pem -pkeyopt dh_paramgen_prime_len:4096
Note Add this to the rest of your
ssl_
directives, be they in thehttp
of/etc/nginx/nginx.conf
, or an HTTPS site’sserver
block:ssl_dhparam /root/certs/example.com/dhparam4096.pem;
Enforce Server-Side Cipher Suite Preferences
Web browsers support many OpenSSL cipher suites, some of which are inefficient or weak. NGINX can impose its TLS cipher suite choices over those of a connecting browser, provided the browser supports them.
If you have selected a good cipher suite combination with NGINX’s ssl_ciphers
directive, you are increasing the connection’s security because NGINX is telling the browser it only wants to communicate through strong cipher and hashing algorithms.
Add this to the rest of your ssl_
directives, be they in the http
of /etc/nginx/nginx.conf
, or an HTTPS site’s server
block:
- File: /etc/nginx/nginx.conf
1
ssl_prefer_server_ciphers on;
Increase Keepalive Duration
SSL/TLS handshakes use a non-negligible amount of CPU power, so minimizing the amount of handshakes which connecting clients need to perform will reduce your system’s processor use. One way to do this is by increasing the duration of keepalive connections from 60 to 75 seconds. This is safe for HTTP and HTTPS, so can be added to the http
block of /etc/nginx/nginx.conf
or edited if already present.
- File: /etc/nginx/nginx.conf
1
keepalive_timeout 75;
Increase TLS Session Duration
Maintain a connected client’s SSL/TLS session for 10 minutes before needing to re-negotiate the connection. Add these to the rest of your ssl_
directives, be they in the http
or an HTTPS site’s server
block:
- File: /etc/nginx/nginx.conf
1 2
ssl_session_cache shared:SSL:10m; ssl_session_timeout 10m;
Enable HTTP/2 Support
HTTP/2 is the successor to the HTTP/1.1 standard which, among other benefits, reduces page load times and bandwidth used. While the HTTP/2 specification applies to both HTTP and HTTP traffic, web browsers currently do not support unencrypted HTTP/2, so it can only be used with TLS.
The Application-Layer Protocol Negotiation (ALPN) standard used with HTTP/2 requires OpenSSL 1.0.2+, so if you intend to enable HTTP/2 on a Linux distribution which uses a prior version of OpenSSL, you will first need to compile and install OpenSSL 1.0.2 or later. Second, you will then need to compile NGINX with that version of OpenSSL.
To check your distribution’s version of OpenSSL, run:
openssl version
Add the
http2
option to thelisten
directive in your site configuration’sserver
block for both IPv4 and IPv6. It should look like below:listen 443 ssl http2; listen [::]:443 ssl http2;
Reload NGINX:
nginx -s reload
Verify HTTP/2 is enabled with the KeyCDN HTTP/2 Test. The result should tell you that your site supports HTTP/2.
OCSP Stapling
When enabled, NGINX will make OCSP requests on behalf of connecting browsers. The response received from the OCSP server is added to NGINX’s browser response, which eliminates the need for browsers to verify a certificate’s revocation status by connecting directly to an OCSP server.
Add the following directives to your
nginx.conf
file, or to theserver
block of your HTTPS site. If you have been following this series, then your certificates are located at/root/certs/example.com/
.- File: /etc/nginx/nginx.conf
1 2 3
ssl_stapling on; ssl_stapling_verify on; ssl_trusted_certificate /root/certs/example.com/cert.crt;
Reload NGINX:
nginx -s reload
Verify OCSP stapling is working properly:
openssl s_client -connect example.org:443 -tls1 -tlsextdebug -status
The return response should show a field of OCPS response data. If instead the command returns OCSP response: no response sent, then recheck your configuration.
Further Reading and Examples
Above are some of the most significant ways you can harden TLS connections between NGINX and client devices. There is more which can be done, but beware of creating a configuration which goes against your use case. Remember, simplicity and safety is always better than a highly “tweaked”, fragile, and untested configuration.
Here are a few sites with more information which you should consider to be recommended reading. Linode does not guarantee their accuracy over time.
NGINX Docs, HTTPS configurations
Strong SSL Security on nginx, raymii.org
OWASP Secure Configuration Guide: NGINX
Full Configuration Example
- File: /etc/nginx/nginx.conf
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
user nginx; worker_processes auto; error_log /var/log/nginx/error.log warn; pid /var/run/nginx.pid; events { worker_connections 1024; } http { include /etc/nginx/mime.types; default_type application/octet-stream; log_format main '$remote_addr - $remote_user [$time_local] "$request" ' '$status $body_bytes_sent "$http_referer" ' '"$http_user_agent" "$http_x_forwarded_for"'; access_log /var/log/nginx/access.log main; sendfile on; #tcp_nopush on; #gzip on; include /etc/nginx/conf.d/*.conf; server_tokens off; keepalive_timeout 75; add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always; add_header X-Content-Type-Options nosniff; add_header X-Frame-Options SAMEORIGIN; add_header X-XSS-Protection "1; mode=block"; add_header Referrer-Policy strict-origin-when-cross-origin; add_header Content-Security-Policy "default-src 'self'; upgrade-insecure-requests;"; ssl_certificate /root/certs/example.com/example.com.crt; ssl_certificate_key /root/certs/example.com/example.com.key; ssl_ciphers EECDH+AESGCM:EDH+AESGCM:AES256+EECDH:AES256+EDH; ssl_dhparam /root/certs/example.com/dhparam4096.pem; ssl_prefer_server_ciphers on; ssl_protocols TLSv1 TLSv1.1 TLSv1.2; ssl_session_cache shared:SSL:10m; ssl_session_timeout 10m; ssl_stapling on; ssl_stapling_verify on; ssl_trusted_certificate /root/certs/example.com/cert.crt; proxy_cache_path /var/www/example.com/cache/ keys_zone=one:10m inactive=60m use_temp_path=off; }
- File: /etc/nginx/conf.d/example.com
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
server { listen 80; listen [::]:80; server_name example.com www.example.com; return 301 https://example.com$request_uri; } server { listen 443 ssl http2 default_server; listen [::]:443 ssl http2 default_server; server_name example.com www.example.com; root /var/www/example.com; index index.html; location / { proxy_cache one; proxy_pass http://localhost:8000; } add_header Feature-Policy "encrypted-media 'self'; autoplay 'none'"; }
Verify Full Configuration
Reload your NGINX configuration:
nginx -s reload
The Qualys SSL Server Test is one of the most comprehensive SSL/TLS connection tests available (but doesn’t work with self-signed certificates). Enter your domain in the form field and run the test.
Analyze the results carefully, and compare the NGINX options you changed in this guide with the test results. Is everything showing as enabled or otherwise working properly? If not, check through your configuration again.
