What is HAProxy?

HAProxy (High Availability Proxy) is a TCP/HTTP load balancer and proxy server that allows a webserver to spread incoming requests across multiple endpoints. This is useful in cases where too many concurrent connections over-saturate the capability of a single server. Instead of a client connecting to a single server which processes all of the requests, the client will connect to an HAProxy instance, which will use a reverse proxy to forward the request to one of the available endpoints, based on a load-balancing algorithm.

This guide will describe the installation and configuration of HAProxy for load-balancing HTTP requests, but the configuration can be adapted for most load-balancing scenarios. The setup is simplified from a typical production setup and will use a single HAProxy node with two web server nodes which will service the requests forwarded from the HAProxy node.

Before You Begin

  1. This guide will use sudo wherever possible. Complete the sections of our Securing Your Server guide to create a standard user account, harden SSH access and remove unnecessary network services.

  2. Update your system:

    sudo apt-get update && sudo apt-get upgrade

  3. This guide uses private IP addresses in the example configurations. Refer to our Linux Static IP Configuration guide to add private IP addresses and internally network your Linodes.

Note
This guide is written for a non-root user. Commands that require elevated privileges are prefixed with sudo. If you’re not familiar with the sudo command, see the Users and Groups guide.

Installation

HAProxy is included in the package management systems of most Linux distributions:

  • Ubuntu 17.04:

      sudo apt-get install haproxy

  • Fedora 26:

      sudo yum install haproxy


Initial Configuration

  1. Review the default configuration file at /etc/haproxy/haproxy.cfg, which is created automatically during installation. This file defines a standard setup without any load balancing:

    File: /etc/haproxy/haproxy.cfg
     1
     2
     3
     4
     5
     6
     7
     8
     9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37

    global
        log /dev/log    local0
        log /dev/log    local1 notice
        chroot /var/lib/haproxy
        stats socket /run/haproxy/admin.sock mode 660 level admin
        stats timeout 30s
        user haproxy
        group haproxy
        daemon

        # Default SSL material locations
        ca-base /etc/ssl/certs
        crt-base /etc/ssl/private

        # Default ciphers to use on SSL-enabled listening sockets.
        # For more information, see ciphers(1SSL). This list is from:
        #  https://hynek.me/articles/hardening-your-web-servers-ssl-ciphers/
        # An alternative list with additional directives can be obtained from
        #  https://mozilla.github.io/server-side-tls/ssl-config-generator/?server=haproxy
        ssl-default-bind-ciphers ECDH+AESGCM:DH+AESGCM:ECDH+AES256:DH+AES256:ECDH+AES128:DH+AES:RSA+AESGCM:RSA+AES:!aNULL:!MD5:!DSS
        ssl-default-bind-options no-sslv3

    defaults
        log     global
        mode    http
        option  httplog
        option  dontlognull
        timeout connect 5000
        timeout client  50000
        timeout server  50000
        errorfile 400 /etc/haproxy/errors/400.http
        errorfile 403 /etc/haproxy/errors/403.http
        errorfile 408 /etc/haproxy/errors/408.http
        errorfile 500 /etc/haproxy/errors/500.http
        errorfile 502 /etc/haproxy/errors/502.http
        errorfile 503 /etc/haproxy/errors/503.http
        errorfile 504 /etc/haproxy/errors/504.http

    The global section defines system level parameters such as file locations and the user and group under which HAProxy is executed. In most cases you will not need to change anything in this section. The user haproxy and group haproxy are both created during installation.

    The defaults section defines additional logging parameters and options related to timeouts and errors. By default, both normal and error messages will be logged.

  2. If you wish to disable normal operation messages from being logged you can add the following after option dontlognull:

    option dontlog-normal

  3. You can also choose to have the error logs in a separate log file:

    option log-separate-errors


Configure Load Balancing

When you configure load balancing using HAProxy, there are two types of nodes which need to be defined: frontend and backend. The frontend is the node by which HAProxy listens for connections. Backend nodes are those by which HAProxy can forward requests. A third node type, the stats node, can be used to monitor the load balancer and the other two nodes.

  1. Open /etc/haproxy/haproxy.cfg in a text editor and append the configuration for the front end:

    File: /etc/haproxy/haproxy.cfg
    1
    2
    3
    4

    frontend haproxynode
        bind *:80
        mode http
        default_backend backendnodes
    Note
    Throughout this guide, replace 203.0.113.2 with the IP address of your frontend node. 192.168.1.3 and 192.168.1.4 will be used as the IP addresses for the backend nodes.

    This configuration block specifies a frontend node named haproxynode, which is bound to all network interfaces on port 80. It will listen for HTTP connections (it is possible to use TCP mode for other purposes) and it will use the back end backendnodes.

  2. Add the back end configuration:

    File: /etc/haproxy/haproxy.cfg
    1
    2
    3
    4
    5
    6
    7
    8

    backend backendnodes
        balance roundrobin
        option forwardfor
        http-request set-header X-Forwarded-Port %[dst_port]
        http-request add-header X-Forwarded-Proto https if { ssl_fc }
        option httpchk HEAD / HTTP/1.1\r\nHost:localhost
        server node1 192.168.1.3:8080 check
        server node2 192.168.1.4:8080 check

    This defines backendnodes and specifies several configuration options:

    • The balance setting specifies the load-balancing strategy. In this case, the roundrobin strategy is used. This strategy uses each server in turn but allows for weights to be assigned to each server: servers with higher weights are used more frequently. Other strategies include static-rr, which is similar to roundrobin but does not allow weights to be adjusted on the fly; and leastconn, which will forward requests to the server with the lowest number of connections.
    • The forwardfor option ensures the forwarded request includes the actual client IP address.
    • The first http-request line allows the forwarded request to include the port of the client HTTP request. The second adds the proto-header containing https if ssl_fc, a HAProxy system variable, returns true. This will be the case if the connection was first made via an SSL/TLS transport layer.
    • Option httpchk defines the check HAProxy uses to test if a web server is still valid for forwarding requests. If the server does not respond to the defined request it will not be used for load balancing until it passes the test.
    • The server lines define the actual server nodes and their IP addresses, to which IP addresses will be forwarded. The servers defined here are node1 and node2, each of which will use the health check you have defined.
  3. Add the optional stats node to the configuration:

    File: /etc/haproxy/haproxy.cfg
    1
    2
    3
    4
    5
    6

    listen stats
        bind :32700
        stats enable
        stats uri /
        stats hide-version
        stats auth someuser:password

    The HAProxy stats node will listen on port 32700 for connections and is configured to hide the version of HAProxy as well as to require a password login. Replace password with a more secure password. In addition, it is recommended to disable stats login in production.

  4. Here is the complete configuration file after modifications:

    File: /etc/haproxy/haproxy.cfg
     1
     2
     3
     4
     5
     6
     7
     8
     9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37
    38
    39
    40
    41
    42
    43
    44
    45
    46
    47
    48
    49
    50
    51
    52
    53
    54
    55
    56
    57
    58

    global
        log /dev/log    local0
        log /dev/log    local1 notice
        chroot /var/lib/haproxy
        stats socket /run/haproxy/admin.sock mode 660 level admin
        stats timeout 30s
        user haproxy
        group haproxy
        daemon

        # Default SSL material locations
        ca-base /etc/ssl/certs
        crt-base /etc/ssl/private

        # Default ciphers to use on SSL-enabled listening sockets.
        # For more information, see ciphers(1SSL). This list is from:
        #  https://hynek.me/articles/hardening-your-web-servers-ssl-ciphers/
        # An alternative list with additional directives can be obtained from
        #  https://mozilla.github.io/server-side-tls/ssl-config-generator/?server=haproxy
        ssl-default-bind-ciphers ECDH+AESGCM:DH+AESGCM:ECDH+AES256:DH+AES256:ECDH+AES128:DH+AES:RSA+AESGCM:RSA+AES:!aNULL:!MD5:!DSS
        ssl-default-bind-options no-sslv3

    defaults
        log     global
        mode    http
        option  httplog
        option  dontlognull
        timeout connect 5000
        timeout client  50000
        timeout server  50000
        errorfile 400 /etc/haproxy/errors/400.http
        errorfile 403 /etc/haproxy/errors/403.http
        errorfile 408 /etc/haproxy/errors/408.http
        errorfile 500 /etc/haproxy/errors/500.http
        errorfile 502 /etc/haproxy/errors/502.http
        errorfile 503 /etc/haproxy/errors/503.http
        errorfile 504 /etc/haproxy/errors/504.http

    frontend haproxynode
        bind *:80
        mode http
        default_backend backendnodes

    backend backendnodes
        balance roundrobin
        option forwardfor
        http-request set-header X-Forwarded-Port %[dst_port]
        http-request add-header X-Forwarded-Proto https if { ssl_fc }
        option httpchk HEAD / HTTP/1.1\r\nHost:localhost
        server node1 192.168.1.3:8080 check
        server node2 192.168.1.4:8080 check

    listen stats
        bind :32700
        stats enable
        stats uri /
        stats hide-version
        stats auth someuser:password

Running and Monitoring

  1. Restart the HAProxy service so that the new configuration can take effect:

    sudo service haproxy restart


Now, any incoming requests to the HAProxy node at IP address 203.0.113.2 will be forwarded to an internally networked node with an IP address of either 192.168.1.3 or 192.168.1.4. These backend nodes will serve the HTTP requests. If at any time either of these nodes fails the health check, they will not be used to serve any requests until they pass the test.

In order to view statistics and monitor the health of the nodes, navigate to the IP address or domain name of the frontend node in a web browser at the assigned port, e.g., http://203.0.113.2:32700. This will display statistics such as the number of times a request was forwarded to a particular node as well the number of current and previous sessions handled by the frontend node.
