How to Install Asterisk on CentOS 7

Select distribution:
Traducciones al Español
Estamos traduciendo nuestros guías y tutoriales al Español. Es posible que usted esté viendo una traducción generada automáticamente. Estamos trabajando con traductores profesionales para verificar las traducciones de nuestro sitio web. Este proyecto es un trabajo en curso.
Create a Linode account to try this guide with a $ credit.
This credit will be applied to any valid services used during your first  days.

What is Asterisk?

Asterisk is an open source private branch exchange (PBX) server that uses Session Initiation Protocol (SIP) to route and manage telephone calls. Notable features include customer service queues, music on hold, conference calling, and call recording, among others.

This guide covers the steps necessary to provision a new CentOS 7 Linode as a dedicated Asterisk server for your home or office.

This guide is written for a non-root user. Commands that require elevated privileges are prefixed with sudo. If you’re not familiar with the sudo command, you can check our Users and Groups guide.

Before You Begin

  1. Create a CentOS 7 Linode in your closest data center. A 2GB Linode is enough to handle 10-20 concurrent calls using a non-compressed codec, depending on the processing required on each channel.

  2. Ensure you have followed the Getting Started and Setting Up and Securing a Compute Instance guides to prepare your Linode. Do not complete the steps to set up a firewall.

  3. Update your system:

    sudo yum update
  4. Disable SELinux and reboot your Linode. If you have Lassie enabled, your Linode is back up and running in a few minutes.

    sed -i 's/SELINUX=enforcing/SELINUX=disabled/g' /etc/selinux/config
    sudo systemctl reboot

Configure firewalld

  1. CentOS 7 enables firewalld’s public zone for the default interface (eth0). SSH and DHCPv6 services are also enabled by default. To verify your current firewalld zone:

    sudo firewall-cmd --get-active-zones
    sudo firewall-cmd --permanent --list-services

    That should return:

    [user@asterisk ~]$ sudo firewall-cmd --get-active-zones
      interfaces: eth0


    [user@asterisk ~]$ sudo firewall-cmd --permanent --list-services
    ssh dhcpv6-client
  2. Add the SIP services.

    All the following firewalld rules contain the --permanent flag to ensure the rules persist after a system reboot.
    sudo firewall-cmd --zone=public --permanent --add-service={sip,sips}
  3. Depending on your needs, you may want to add other related ports:

    • MGCP - If you use media gateway control protocol in your configuration.

        sudo firewall-cmd --zone=public --permanent --add-port=2727/udp
    • RTP - The media stream - you can change this in /etc/asterisk/rtp.conf.

        sudo firewall-cmd --zone=public --permanent --add-port=10000-20000/udp
    • If you plan to use FreePBX to manage Asterisk, add the following rule:

        sudo firewall-cmd --zone=public --permanent --add-service={http,https}
    • IAX - If you need IAX, add the following rule. IAX is “Inter-Asterisk Exchange” and was meant to allow multiple Asterisk servers to communicate with one another. Some VOIP trunking providers use this, but most use SIP. Unless your VOIP provider requires it or you are running multiple Asterisk servers, you probably don’t need IAX or IAX2.

        sudo firewall-cmd --zone=public --permanent --add-port=4569/udp
  4. Verify your new configuration with:

    sudo firewall-cmd --permanent --list-services
    sudo firewall-cmd --permanent --list-ports

    You should see the services and ports you just added in addition to default SSH and DCHPv6 services:

    [user@asterisk ~]$ sudo firewall-cmd --list-ports
    2727/udp 10000-20000/udp 4569/udp
    [user@asterisk ~]$ sudo firewall-cmd --permanent --list-services
    ssh dhcpv6-client sip sips http https


PJPROJECT is Asterisk’s SIP channel driver. It should improve call clarity and performance over older drivers.

  1. Install build dependencies:

    sudo yum install epel-release gcc-c++ ncurses-devel libxml2-devel wget openssl-devel newt-devel kernel-devel-`uname -r` sqlite-devel libuuid-devel gtk2-devel jansson-devel binutils-devel bzip2 patch libedit libedit-devel
  2. As a non-root user, create a working directory for the build:

    mkdir ~/build-asterisk
  3. Change to that directory:

    cd ~/build-asterisk
  4. Use wget to download the PJSIP driver source code:

  5. Extract it:

    tar -jxvf pjproject-2.8.tar.bz2
  6. Change to the newly created directory:

    cd pjproject-2.8
  7. Specify the compiling flags and options:

    ./configure CFLAGS="-DNDEBUG -DPJ_HAS_IPV6=1" --prefix=/usr --libdir=/usr/lib64 --enable-shared --disable-video --disable-sound --disable-opencore-amr
  8. Ensure that all dependencies are in place:

    make dep
  9. If make dep completes successfully, then build the plugin. It should only take a few minutes.

  10. Install the packages:

    sudo make install
    sudo ldconfig
  11. Ensure the libraries have been properly installed:

    sudo ldconfig -p | grep pj

    You should see:

    (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/ (libc6,x86-64) => /lib64/

Install Asterisk

  1. Return to your build directory:

    cd ~/build-asterisk
  2. Download the latest version of Asterisk 16:

  3. Untar the file:

    tar -zxvf asterisk-16-current.tar.gz
  4. Switch to the new Asterisk directory, replacing 16.1.1 if needed:

    cd asterisk-16.1.1

Enable MP3 Support

  1. To use MP3 files for Music on Hold, install Subversion:

    sudo yum install svn
  2. Run the configuration script:


Configure and Build Asterisk

  1. In your build directory for Asterisk, run the configure script to prepare the Asterisk source code for compiling:

    ./configure --libdir=/usr/lib64 --with-jansson-bundled
  2. Start the build process. After a short while, you should see a menu on screen allowing you to configure the features you want to build. This also produces generic binaries instead of native architecture optimized binaries.

    make menuselect --disable BUILD_NATIVE menuselect.makeopts
  3. If you want to use the MP3 format with Music on Hold, you should select Add-Ons, then use the right arrow to move to the right-hand list. Navigate to format_mp3 and press Enter to select it.

  4. Select additional core sound packages and Music on Hold packages in the left menu, and enable .wav format for your desired language (ie. use the EN package for English.).

  5. Press F12 to save and exit.

  6. Compile Asterisk. When finished, you should see a message which says Asterisk has successfully been built.

    sudo make
  7. Install Asterisk:

    sudo make install
  8. Install sample configuration files:

    sudo make samples
  9. Configure Asterisk to start itself automatically on boot:

     sudo make config

Test Connection

You now have a working Asterisk phone server. Fire up Asterisk and make sure it runs.

  1. Start Asterisk:

    sudo systemctl start asterisk
  2. To ensure that asterisk service starts even after a reboot, enable the service:

     sudo systemctl enable asterisk
  3. Connect to Asterisk:

    sudo asterisk -rvv

    You should see an output similar to the following:

    Asterisk 16.0.0, Copyright (C) 1999 - 2018, Digium, Inc. and others.
    Created by Mark Spencer <>
    Asterisk comes with ABSOLUTELY NO WARRANTY; type 'core show warranty' for details.
    This is free software, with components licensed under the GNU General Public
    License version 2 and other licenses; you are welcome to redistribute it under
    certain conditions. Type 'core show license' for details.
    Connected to Asterisk 16.0.0 currently running on li73-122 (pid = 980)
  4. To see a list of possible commands:

    core show help
  5. To disconnect type:


    Once disconnected, Asterisk continues to run in the background.

Next Steps

Now that you have an Asterisk server running on your Linode, it’s time to connect some phones, add extensions, and configure the various options that are available with Asterisk. For detailed instructions, check out the Asterisk Project’s guide to Configuring Asterisk.

When running a phone system on a remote server such as a Linode, it’s always good practice to secure the signaling data with TLS and the audio portion of calls using SRTP to prevent eavesdropping. Once you have a working dial-plan, be sure to follow the Secure Calling Guide to encrypt your communications.
