Linode Writer's Formatting Guide

Write Guides for Linode

This guide provides templates and guidelines to use when creating or updating a guide for Linode Docs.

Updates, improvements, and bug fixes to Linode documentation are always welcome through GitHub via pull requests (PRs) or issues.

We only accept new guides and authors through our guide submission process. To apply, please fill out the form on our contribute page.

General Layout

Linode Guides & Tutorials are written in Markdown. Our documentation site uses Hugo, a static site generator. Hugo-specific markdown formatting notes are given further below.

Linode Guides & Tutorials store metadata and other information in a YAML header at the top of every page. Use the template below for your own guide.

Author Submission
 1 2 3 4 5 6 7 8 910111213141516171819
---
author:
  name: Linode Community
  email: docs@linode.com
description: 'Two to three sentences describing the purpose of the guide.'
keywords: ["list", "of", "keywords", "and key phrases"]
license: '[CC BY-ND 4.0](https://creativecommons.org/licenses/by-nd/4.0)'
published: 2017-11-29
modified: 2017-11-30
modified_by:
  name: Linode
title: 'Guide Title'
contributor:
  name: Your Name
  link: Github/Twitter/LinkedIn URL
  external_resources:
- '[Link Title 1](http://www.example.com)'
- '[Link Title 2](http://www.example.net)'
---

If you’re updating an existing guide in our repository, you may also notice a deprecated field in the header. This defaults to false, and setting it to true inserts a pre-written message near the beginning stating that the guide is no longer maintained. Typically, this will be used on guides specific to applications or distributions that have reached End of Life (EOL).

Introduction

Introductions should be concise; explain what the goal of the guide is and why. If you’re introducing new software to the system, include a brief description and link to its official website whenever possible.

Before You Begin

The Before You Begin section is an area for basic prerequisites a reader should know or have completed before proceeding further in your guide. Use the example below and edit as needed:

Author Submission
123456789
## Before You Begin

1.  Familiarize yourself with our [Getting Started](/docs/getting-started) guide and complete the steps for setting your Linode's hostname and timezone.

2.  This guide will use `sudo` wherever possible. Complete the sections of our [Securing Your Server](/docs/security/securing-your-server) to create a standard user account, harden SSH access and remove unnecessary network services.

3.  Update your system:

        sudo apt-get update && sudo apt-get upgrade

Describe Example Variables

If using example variables which should be changed throughout the guide, declare them in the Before You Begin section.

Variables that the reader will need to change for their system or preference should be formatted using backtics. This includes:

Do not include any brackets or parentheses when using these temporary values in examples, as the reader may include them in their final version.

FormattingExample
Change the `password` and `username` values.Change the password and username values.

Include a Note about Root or Non-Root users

Guides Written for a Non-Root User
123
{{< note >}}
This guide is written for a non-root user. Commands that require elevated privileges are prefixed with `sudo`. If you’re not familiar with the `sudo` command, see the [Users and Groups](/docs/tools-reference/linux-users-and-groups) guide.
{{< /note >}}
Guides Written for a Root User
123
{{< note >}}
The steps in this guide require root privileges. Be sure to run the steps below as `root` or with the `sudo` prefix. For more information on privileges, see our [Users and Groups](/docs/tools-reference/linux-users-and-groups) guide.
{{< /note >}}

Paragraph Structure

Guides should be split into cohesive sections which flow from one sequence of events to the next. Each section title should be styled with an H2 heading element, and each subsection with an H3 heading so that scanning the In This Guide left sidebar should give the reader an overview of what will be done in the guide. Capitalize each noun, adjective, verb and adverb in the article title, H2 and H3 headers.

Each subsection should be split into numbered steps as shown below.

For example:

 1 2 3 4 5 6 7 8 91011121314151617181920212223
## Using MySQL

1.  Log in to MySQL as the root user:
        mysql -u root -p

2.  When prompted, enter the root password.

### Create a New MySQL User and Database

1.  In the example below, `testdb` is the name of the database, `testuser` is the user, and `password` is the user’s password.

        create database testdb;
        grant all on testdb.* to 'testuser' identified by 'password';

2.  Exit MySQL.

        exit

### Create a Sample Table

1.  Log back in as `testuser`:

        mysql -u testuser -p
Note
The tab size is set to four, and only soft tabs should be used. This can be configured in the settings of most text editors.

How to Use Markdown Formatting for Linode Style

Abbreviations and Acronyms

Upon first mention of a new concept or software, use the full name or term, then note the abbreviation or acronym in parenthesis beside it. The abbreviation/acronym can then be used in the article from that point. For example: Lightweight Resource/Provider (LWRP).

Introduce new terms in italics with a * on either side of the term:

In this guide, we'll install Git, a *version control system*.

Bold and Italics

Use a Bold font weight for buttons, menu selections and anything that requires emphasis or that you want to stand out to the reader. Italicize new terms and concepts the first time they are used.

FormattingExample
**bold**bold
*italics*italics

Commands

Commands that are not inline with paragraph text should be indented four spaces from the beginning of the copy.

For example:

Update your system:

    yum update

Update your system:

yum update

Inline commands should be denoted by backtics.

FormattingExample
Update your system by running `yum update`.Update your system by running yum update.

Example IP Addresses

Example IPs should use the documentation address blocks given in IETF RFC 5737. These are:

  • 192.0.2.0/24
  • 198.51.100.0/24
  • 203.0.113.0/24

External Resources/More Information

If you wish to provide links to external sites for the user to review after going through your guide, do so using the external_resources field in the page header. This will automatically appear as a text block with links at the bottom of the page.

More Information

You may wish to consult the following resources for additional information on this topic. While these are provided in the hope that they will be useful, please note that we cannot vouch for the accuracy or timeliness of externally hosted materials.

Shortguides

For common tasks such as basic software installation, consider using the section shortcode. This allows our library to maintain consistent and up to date installation instructions for frequently used tools such as Python, MySQL, and Docker.

First, review the available shortguides in the docs/shortguides folder to see if there is already an installation guide for the software you would like to install. If not, you may want to write your own set of instructions and store it in this directory. The filename should make it clear what the instructions are meant to accomplish, for example install_python_miniconda.md.

Shortguides should consist entirely of numbered steps, as they are intended to be inserted into multiple guides:

install_python_miniconda.md
 1 2 3 4 5 6 7 8 910111213
<!-- Installation instructions for Python 3. -->

1.  Download and install Miniconda:

        curl -OL https://repo.continuum.io/miniconda/Miniconda3-latest-Linux-x86_64.sh
        bash Miniconda3-latest-Linux-x86.64.sh

2.  You will be prompted several times during the installation process. Review the terms and conditions and select "yes" for each prompt.


3.  Check your Python version:

        python --version

To use a shortguide in another guide, use the following syntax:

sample_guide.md
1
{{< section file="/shortguides/install_nginx.md" >}}

Files and File Excerpts

Use the file shortcode to add the entire contents of a file to a guide. If only quoting a portion of the file, use the file excerpt shortcode. Exceptionally long files should be shown in parts and have the whole file linked, if needed. For each file or file excerpt, a code language or syntax should be defined in the shortcode tag to set how the text is displayed. A list of supported languages can be found on GitHub.

Example: File shortcode

{{< file path/to/file.html html >}}
    <div>
        Sample file text
    </div>
{{< /file >}}
path/to/file.html
123
<div>
    Sample file text
</div>

Example: File Excerpt shortcode

{{< file-excerpt "script.py" python >}}
def some_function():
    print("This is a function.")
{{< /file-excerpt >}}
script.py
12
def some_function():
    print("This is a function.")

File Paths and File Names

Inline file paths and file names should be unformatted text.

FormattingExample
Navigate to `/var/www/html`.Navigate to /var/www/html.

Headings

FormattingExample
## Section title (h2)Section title (h2)
### Subsection (h3)Subsection (h3)

Images

Images should be in .png or .jpg format. If an image is over 650 pixels wide, include both the original and one which is scaled down to 650 px. Image filenames cannot contain spaces and should use hyphens (-) to separate words instead of underscores (_).

When adding an image, ensure that all identifying attributes such as names and IP addresses are removed, obfuscated, or replaced with dummy text, such as example_user or 192.0.2.0. Be mindful of metadata in images taken with mobile devices.

Up to 650 px wide.Over 650 px wide.
![Description of the image](/docs/assets/filename.png “Description of the image.”)[![Description of the image](/docs/assets/filename_small.png)](/docs/assets/filename.png “Description of the image.”)

Key Combinations

When instructing a reader to use a combination of keys, format the key combination in bold.

FormattingExample
Press **CTRL+N** then **X** to exit the program.Press CTRL+N then X to exit the program.

Internal links to other Linode guides should be relative, starting at /docs/, and external links should be formatted as shown below and use HTTPS URLs whenever possible.

InternalExternal
[Getting Started](/docs/getting-started)[Apache HTTP Server Documentation](https://httpd.apache.org/docs/)

Lists

Be sure that lists have the proper horizontal spacing. This should be two spaces for ordered lists and three for unordered. This is to keep the lists aligned properly with the four-space soft tabs used in the guides.

OrderedUnordered
1.  Step 1.

2.  Step 2.

3.  Step 3.
*   Item 1.

*   Item 2.

*   Item 3.

Notes and Cautions

Notes should be important text that does not necessarily fit the narrative of the preceding step or paragraph. If a step in your guide can cause any major issues with the user’s Linode or computer, a caution note should be included.

{{< note >}}
This is a sample note.
{{< /note >}}
Note
This is a sample note.
{{< caution >}}
This is a sample caution.
{{< caution >}}
Caution
This is a sample caution.

Numerical Values

1-10Greater than 10
Use words (one, two, three, etc.)Use numerical digits (11, 22, 33).

Sentence Spacing

Use single spaces between sentences; do not double-space.

Tables

FormattingExample

| Left-Aligned | Centered | Right-Aligned |
| ---------------- |:-------------:| -----------------:|
| Columns,     | both          | headers        |
| and              | line items, | are aligned   |
| by the hyphens | and colons | above.     |
