Set Up an IPv6 Tunnel on Your Linode

Updated by Phil Zona

Contribute on GitHub

View Project | View File | Edit File

As IPv4 address exhaustion nears, many people are making the switch to IPv6. Linode offers native IPv6 addresses in all locations.

An IPv6 tunnel lets a system reach an IPv6 network using existing IPv4 connectivity. Follow this guide if you:

  • Have a tunnel that you are migrating to your Linode;
  • Want to increase your IPv6 footprint for redundancy and failover in case of routing issues;
  • Don’t have IPv6 from your ISP, and want to interact with your Linode through its IPv6 address. By configuring the tunnel to a local computer instead of your Linode, you can connect to your Linode via the IPv6 address.

Before You Begin

You should have already signed up for an IPv6 tunnel through a tunnel broker. Wikipedia contains a list of tunnel brokers by region, and we encourage you to research each before you decide which to use. The steps outlined in this guide were performed using tunnels from Hurricane Electric (HE).

General Setup

Once you have signed up for a tunnel, you will need to issue a few commands on your Linode. Arch and Gentoo Linux users may need to install the iproute2 package before continuing.

Configuration of an IP tunnel using this method will not be persistent after reboot and will need to be reconfigured after restarting your Linode.

  1. Because some of these steps will temporarily disable networking on the Linode, begin by logging in using either the Lish or Glish interface.

  2. Use the ip tool to add the tunnel device. Ours is called he-ipv6 to match the device described in Hurricane Electric’s examples. Replace 203.0.113.10 with the endpoint of your tunnel, and 198.51.100.5 with your Linode’s IP address. The information for the endpoint can be found in your tunnel broker’s web interface, and your Linode’s IP address can be found under the Remote Access tab of the Linode Manager:

    1
    2
    ip tunnel add he-ipv6 mode sit remote 203.0.113.10 local 198.51.100.5 ttl 255
    ip link set he-ipv6 up


    For more information on how the ip tool configures tunnels, see the ip-tunnel documentation.

  3. Assign IPv6 address and routing information to your new tunnel device. Replace 2001:db8:1234:5678::2/64 with the IPv6 address assigned to you. This information should be provided to you by your tunnel broker as your “Client IPv6 Address”:

    The ifdown command will halt all network traffic to your Linode. This step is included to avoid an error when adding the IPv6 route. It may not be required on all Linux distributions.

    On Arch Linux, replace the ifdown and ifup commands with ip link set eth0 down and ip link set eth0 up

    1
    2
    3
    4
    5
    ip addr add 2001:db8:1234:5678::2/64 dev he-ipv6
    ifdown eth0
    ip route add ::/0 dev he-ipv6
    ifup eth0
    ip -f inet6 addr


    The final command in Line 5 will show all devices with IPv6 addresses, and should have a block similar to this:

    1
    2
    3
    4
    5
    13: he-ipv6@NONE: <POINTOPOINT,NOARP,UP,LOWER_UP> mtu 1480 state UNKNOWN qlen 1
        inet6 2001:db8:1234:5678::2/64 scope global
           valid_lft forever preferred_lft forever
        inet6 fe80::0000:0000/64 scope link
           valid_lft forever preferred_lft forever

  4. Test the tunnel. Replace he-ipv6 with the name of your tunnel:

    1
    ping6 -I he-ipv6 irc6.oftc.net


    On Arch Linux and other distributions without ping6, use ping -6 instead.

If everything is working, you should see ping replies. If not, go back and make sure that you haven’t made any errors.

Manual Configuration

The instructions in this section will allow you to manually configure your IPv6 tunnel. This can permanently affect your connectivity across reboots. Read the IPv6 documentation for your distribution before proceeding.

When manually modifying your network configuration, always disable Network Helper first to avoid having your changes overwritten on reboot.

Debian and Ubuntu

Debian and Ubuntu users (versions before Ubuntu 16.04 are not covered here) can perform the following steps to set up a tunnel on their Linode.

  1. In the following excerpt, replace the:

    • address value with the “Client IPv6 address.”
    • gateway value with the “Server IPv6 address.”
    • endpoint value with the endpoint, or “Server IPv4 Address,” that your tunnel broker provides you. Generally this endpoint is in a geographical location that is close to your Linode.
    • local value with your Linode’s IP address. If you have multiple IPs, make sure that this IP is set to the same address as the one you used to sign up for the tunnel.

    Insert the following into your /etc/network/interfaces file:

    /etc/network/interfaces
    1
    2
    3
    4
    5
    6
    7
    8
    auto he-ipv6
    iface he-ipv6 inet6 v4tunnel
        address 2001:db8:1234:5678::2
        netmask 64
        endpoint 203.0.113.10
        local 198.51.100.5
        ttl 255
        gateway 2001:db8:1234:5678::1

  2. Restart networking services and test the tunnel. Replace he-ipv6 with the name of your tunnel:

    1
    2
    systemctl restart networking.service
    ping6 -I he-ipv6 irc6.oftc.net


    If configuration was successful, you will receive ping replies. If not, check your network configuration for errors.

CentOS 7 and Fedora 22+

  1. Create a file at /etc/sysconfig/network-scripts/ifcfg-he-ipv6 that contains the following:

    /etc/sysconfig/network-scripts/ifcfg-he-ipv6
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    NAME="he-ipv6"
    DEVICE=he-ipv6
    ONBOOT=yes
    USERCTL=yes
    BOOTPROTO=none
    PEERDNS=no

    IPV6INIT=yes
    IPV6_AUTOTUNNEL=yes
    IPV6ADDR="2001:db8:1234:5678::2/64"
    IPV6_ROUTER=yes
    IPV6_AUTOCONF=no

    IPV6_CONTROL_RADVD=yes
    IPV6TUNNELIPV4=203.0.113.10
    IPV6TUNNELIPV4LOCAL=45.79.171.199

    PHYSDEV=eth0
    TYPE=sit
    DEVICETYPE=sit
    NM_CONTROLLED=no

    IPV6_DEFAULTGW=2001:db8:1234:5678::1
    IPV6_DEFAUTLDEV=he-ipv6


    In the above, replace the:

    • IPV6ADDR value with your “Client IPV6 Address.”
    • IPV6TUNNELIPV4 value with your “Server IPV4 Address.”
    • IPV6TUNNELIPV4LOCAL value with your “Client IPV4 Address.”
    • IPV6_DEFAULTGW value with your “Server IPV6 Address.”
  2. Start the he-ipv6 interface:

    1
    ifup he-ipv6

  3. Test the tunnel. Replace he-ipv6 with the name of your tunnel:

    1
    ping6 -I he-ipv6 irc6.oftc.net


    If configuration was successful, you will receive ping replies. If not, check your network configuration for errors.

CentOS 6

  1. Add the following lines to your /etc/sysconfig/network file:

    /etc/sysconfig/network
    1
    2
    NETWORKING_IPV6=yes
    IPV6_DEFAULTDEV=he-ipv6

  2. Create a file at /etc/sysconfig/network-scripts/ifcfg-he-ipv6 that contains the following:

    /etc/sysconfig/network-scripts/ifcfg-he-ipv6
    1
    2
    3
    4
    5
    6
    DEVICE=he-ipv6
    BOOTPROTO=none
    ONBOOT=yes
    IPV6INIT=yes
    IPV6TUNNELIPV4=203.0.113.10
    IPV6ADDR=2001:db8:1234:5678::2/64


    Replace the IPV6TUNNELIPV4 value with your remote tunnel endpoint and the IPV6ADDR value with the “Client IPv6” address provided to you by your tunnel broker.

  3. Start the he-ipv6 interface:

    1
    ifup he-ipv6

  4. Test the tunnel. Replace he-ipv6 with the name of your tunnel:

    1
    ping6 -I he-ipv6 irc6.oftc.net


    If configuration was successful, you will receive ping replies. If not, check your network configuration for errors.

Arch Linux

Refer to the Arch Linux Wiki for more information.

Gentoo Linux

Refer to the Gentoo Linux Wiki for more information.
