OpenVPN is a tool for creating networking tunnels between and among groups of computers that are not on the same local network. This is useful if you want to remotely access services on a network or computer without making those services publicly accessible. When integrated with OpenSSL, OpenVPN can encrypt all VPN traffic to provide a secure connection between machines.

This guide is the first of a three-part series. Part one will set you up with a hardened VPN server in Debian and prepare the certificate and key pairs for connecting client devices. This VPN can be used to host internal services such as websites, game servers or file servers.

Part two will show you how to set up a classic routed VPN, where all traffic from client devices is tunneled through your Linode and out to the internet. Part three walks through setting up the client-side credentials and software for various operating systems, including mobile platforms.

Before You Begin

  1. Familiarize yourself with our Getting Started guide and complete the steps for setting your Linode’s timezone.

  2. This guide will use sudo wherever possible. Complete the sections of our Securing Your Server guide to create a standard user account, harden SSH access and remove unnecessary network services. Do not follow the Creating a Firewall section–this guide has instructions specifcally for firewall rules for an OpenVPN server.

  3. Update your system:

    1
    sudo apt-get update && sudo apt-get upgrade


Managing the OpenVPN Environment

You can manage the OpenVPN environment in two ways:

  • The first method uses OpenVPN Community Edition, where server and client configuration files are manually edited and client credentials are copied to their respective devices using SCP or SFTP. If you don’t already have an application for remote file transfers on your device, you would need to install one. Alternatively, you could copy credentials to a desktop computer, edit them and then transfer them by USB.

  • The second method uses OpenVPN Access Server, a server-side application which lets you configure OpenVPN through a GUI in your web browser. Client machines access a private URL from which to download their credential packages.

For small applications, OpenVPN Access Server is the more streamlined and user-friendly solution. The free version allows up to two simultaneous users and, although each user can have as many client devices as they like, a user’s clients will all have the same keys and certificates. More can be added by buying licensing. For more advanced configurations than what the GUI offers though, you would still need to resort to editing config files.

If you are interested running OpenVPN Access Server on your Linode, see our guide: Secure Communications with OpenVPN Access Server. The remainder of this guide will focus on manual configuration using OpenVPN Community Edition.

Networking Rules

OpenVPN currently does not support a dual-stack configuration from a single instance where clients can connect to a server simultaneously using IPv4 and IPv6; one transport layer must be chosen or the other.

This feature is planned for OpenVPN 2.4, but it will still be some time before that is released. Furthermore, only OpenVPN version 2.3 and above support IPv6 over TUN devices. With versions earlier than 2.3, IPv6 can only be used with TAP devices, so some clients can be further limited.

For these reasons, this series assumes your VPN will operate over IPv4 only. If you instead wish to use IPv6, see OpenVPN’s documentation for more information.

IPv4 Firewall

  1. Flush any pre-existing rules and non-standard chains which may be in the system:

    1
    sudo iptables -F && sudo iptables -X

  2. See our Securing Your Server guide and complete the section on iptables for Debian using the ruleset below:

    /tmp/v4
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37
    38
    39
    40
    41
    42
    43
    44
    45
    46
    *filter

    # Allow all loopback (lo) traffic and reject anything
    # to localhost that does not originate from lo.
    -A INPUT -i lo -j ACCEPT
    -A INPUT ! -i lo -s 127.0.0.0/8 -j REJECT
    -A OUTPUT -o lo -j ACCEPT

    # Allow ping and ICMP error returns.
    -A INPUT -p icmp -m state --state NEW --icmp-type 8 -j ACCEPT
    -A INPUT -p icmp -m state --state ESTABLISHED,RELATED -j ACCEPT
    -A OUTPUT -p icmp -j ACCEPT

    # Allow SSH.
    -A INPUT -i eth0 -p tcp -m state --state NEW,ESTABLISHED --dport 22 -j ACCEPT
    -A OUTPUT -o eth0 -p tcp -m state --state ESTABLISHED --sport 22 -j ACCEPT

    # Allow UDP traffic on port 1194.
    -A INPUT -i eth0 -p udp -m state --state NEW,ESTABLISHED --dport 1194 -j ACCEPT
    -A OUTPUT -o eth0 -p udp -m state --state ESTABLISHED --sport 1194 -j ACCEPT

    # Allow DNS resolution and limited HTTP/S on eth0.
    # Necessary for updating the server and keeping time.
    -A INPUT -i eth0 -p udp -m state --state ESTABLISHED --sport 53 -j ACCEPT
    -A OUTPUT -o eth0 -p udp -m state --state NEW,ESTABLISHED --dport 53 -j ACCEPT
    -A INPUT -i eth0 -p tcp -m state --state ESTABLISHED --sport 80 -j ACCEPT
    -A INPUT -i eth0 -p tcp -m state --state ESTABLISHED --sport 443 -j ACCEPT
    -A OUTPUT -o eth0 -p tcp -m state --state NEW,ESTABLISHED --dport 80 -j ACCEPT
    -A OUTPUT -o eth0 -p tcp -m state --state NEW,ESTABLISHED --dport 443 -j ACCEPT

    # Allow traffic on the TUN interface.
    -A INPUT -i tun0 -j ACCEPT
    -A OUTPUT -o tun0 -j ACCEPT

    # Log any packets which don't fit the rules above...
    # (optional but useful)
    -A INPUT -m limit --limit 3/min -j LOG --log-prefix "iptables_INPUT_denied: " --log-level 4
    -A FORWARD -m limit --limit 3/min -j LOG --log-prefix "iptables_FORWARD_denied: " --log-level 4
    -A OUTPUT -m limit --limit 3/min -j LOG --log-prefix "iptables_OUTPUT_denied: " --log-level 4

    # then reject them.
    -A INPUT -j REJECT
    -A FORWARD -j REJECT
    -A OUTPUT -j REJECT

    COMMIT


    The TUN virtual interface is how the OpenVPN daemon communicates with your Linode’s eth0 hardware interface.

    You can see your loaded rule list with sudo iptables -S. For more specialized firewall rules, see: /usr/share/doc/openvpn/examples/sample-config-files/firewall.sh.

Disable IPv6

If you are exclusively using IPv4 on your VPN, IPv6 should be disabled unless you have a specific reason not to do so.

  1. Add the following lines to /etc/sysctl.d/99-sysctl.conf:

    1
    2
    3
    4
    net.ipv6.conf.all.disable_ipv6 = 1
    net.ipv6.conf.default.disable_ipv6 = 1
    net.ipv6.conf.lo.disable_ipv6 = 1
    net.ipv6.conf.eth0.disable_ipv6 = 1

  2. Activate the sysctl changes immediately:

    1
    sudo sysctl -p

  3. Go into /etc/hosts and comment out the line for IPv6 resolution over localhost.

    /etc/hosts
    1
    #::1     localhost ip6-localhost ip6-loopback

  4. Add an ip6tables ruleset to reject all v6 traffic. Your rules.v6 file should look like this:

    /etc/iptables/rules.v6
    1
    2
    3
    4
    5
    6
    7
    *filter

    -A INPUT -j REJECT
    -A FORWARD -j REJECT
    -A OUTPUT -j REJECT

    COMMIT

  5. Enforce the ruleset immediately:

    1
    sudo ip6tables-restore < /etc/iptables/rules.v6


Install and Configure OpenVPN

For these next sections, you need a root shell.

1
sudo su -
  1. Start by installing OpenVPN:

    1
    apt-get install openvpn

  2. OpenVPN’s server-side configuration file is /etc/openvpn/server.conf which must be extracted from the archive of config templates.

    1
    gunzip -c /usr/share/doc/openvpn/examples/sample-config-files/server.conf.gz > /etc/openvpn/server.conf

  3. Run the make-cadir script to copy over the necessary files from /usr/share/doc/openvpn/examples/ and create our working directory. Then change location into it:

    1
    make-cadir /etc/openvpn/easy-rsa && cd /etc/openvpn/easy-rsa/

  4. Create a symbolic link from openssl-1.0.0.cnf to openssl.cnf:

    1
    ln -s openssl-1.0.0.cnf openssl.cnf

  5. The permissions of /etc/openvpn/easy-rsa/keys are 0700, which do not allow for group or world access to the key and certificate files. For this reason, keep keys as the storage location for server credentials by specifying the absolute paths in OpenVPN’s server.conf.

    /etc/openvpn/server.conf
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    # Any X509 key management system can be used.
    # OpenVPN can also use a PKCS #12 formatted key file
    # (see "pkcs12" directive in man page).
    ca /etc/openvpn/easy-rsa/keys/ca.crt
    cert /etc/openvpn/easy-rsa/keys/server.crt
    key /etc/openvpn/easy-rsa/keys/server.key  # This file should be kept secret

    # Diffie hellman parameters.
    # Generate your own with:
    #   openssl dhparam -out dh1024.pem 1024
    # Substitute 2048 for 1024 if you are using
    # 2048 bit keys.
    dh /etc/openvpn/dh4096.pem

  6. The vars file in /etc/openvpn/easy-rsa contains presets used by the easy-rsa scripts. Here you can specify identification information for your OpenVPN server’s certificate authority, which then will be passed to client certificates. Changing these fields is optional and you can always input them manually during certificate creation, but setting them here creates less work during client cert creation.

    /etc/openvpn/easy-rsa/vars
    1
    2
    3
    4
    5
    6
    7
    8
    9
    # These are the default values for fields
    # which will be placed in the certificate.
    # Don't leave any of these fields blank.
    export KEY_COUNTRY="US"
    export KEY_PROVINCE="CA"
    export KEY_CITY="SanFrancisco"
    export KEY_ORG="Fort-Funston"
    export KEY_EMAIL="me@myhost.mydomain"
    export KEY_OU="MyOrganizationalUnit"

  7. From the easy-rsadirectory, source the vars script:

    1
    cd /etc/openvpn/easy-rsa && source ./vars


    This will return:

    1
    NOTE: If you run ./clean-all, I will be doing a rm -rf on /etc/openvpn/easy-rsa/keys

  8. Run the clean-all script to be sure you’re starting with no samples or templates in your keys folder.

    1
    ./clean-all


Generate Diffie-Hellman PEM

The Diffie-Hellman parameter is a chunk of randomly generated data used when establishing Perfect Forward Secrecy during creation of a client’s session key. We’ll create the file at /etc/openvpn/dh*.pem, where * indicates the bit length of the Diffie-Hellman key. 2048 bits is the default, but here we’ll use a 4096 bit key.

Create the file with:

1
openssl dhparam 4096 > /etc/openvpn/dh4096.pem

This should produce the following output:

1
2
Generating DH parameters, 4096 bit long safe prime, generator 2
This is going to take a long time

Depending on the size of your Linode, this will take about 5 minutes to complete. When finished, it will return you to the command prompt.

To permanently change the default DH PEM size, edit the bit lengths in vars and server.conf. Then, recreate the file. The DH PEM file can be arbitrarily deleted and regenerated without needing to change server or client settings.

Harden OpenVPN

An OpenVPN connection consists of two flow channels between the server and clients: the Control Channel and the Data Channel. A client connects to the server by initiating a TLS session over the control channel, in which credentials are exchanged between server and clients to establish the data channel. The data channel is the encrypted pipeline in which all traffic between server and clients is then transmitted.

Further changes to server.conf are made to strengthen the cryptography used in both channels and restrict the OpenVPN’s daemon’s privileges. These settings can be applied independently of each other, so if you feel that a certain step adds unnecessary complexity, feel free to skip it.

  1. Require a matching HMAC signature for all packets involved in the TLS handshake between the server and connecting clients. Packets without this signature are dropped. Uncomment (by removing the ;) and edit the line: tls-auth ta.key 0 # This file is secret.

    /etc/openvpn/server.conf
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    # For extra security beyond that provided
    # by SSL/TLS, create an "HMAC firewall"
    # to help block DoS attacks and UDP port flooding.
    #
    # Generate with:
    #   openvpn --genkey --secret ta.key
    #
    # The server and each client must have
    # a copy of this key.
    # The second parameter should be '0'
    # on the server and '1' on the clients.
    tls-auth /etc/openvpn/easy-rsa/keys/ta.key 0 # This file is secret


    Generate the HMAC key file. Later we’ll transfer it to each client device:

    1
    openvpn --genkey --secret /etc/openvpn/easy-rsa/keys/ta.key

  2. Create a new limited user account for the OpenVPN daemon to run as and tell it to drop privileges to that account after startup. As an example, the name openvpn_server is used.

    1
    adduser --system --shell /usr/sbin/nologin --no-create-home openvpn_server


    Uncomment the user and group lines, and edit user with the username above. This tells the daemon to drop root privileges and switch to the openvpn_server user after startup.

    /etc/openvpn/server.conf
    1
    2
    3
    4
    5
    6
    7
    # It's a good idea to reduce the OpenVPN
    # daemon's privileges after initialization.
    #
    # You can uncomment this out on
    # non-Windows systems.
    user openvpn_server
    group nogroup


    By default, OpenVPN runs as root. While the user nobody has much fewer priviledges than root, if nobody gets compromized, an intruder will have full access to anything else that user has access to. This includes other processes which run as nobody such as Apache, various NFS mounts and some cron jobs.

    Forcing OpenVPN to run under its own account is a good way to isolate it from the rest of the system, especially if you will also be hosting a web or file server on your VPN.

  3. Change the VPN’s data channel to use AES with a 256 bit key in CBC mode. Blowfish-128 is the default, but AES_CBC is generally considered the most secure cipher and mode combination of those supported by OpenVPN (see openvpn --show-ciphers), and can take advantage of AES-NI for increased performance.

    1
    echo 'cipher AES-256-CBC' >> /etc/openvpn/server.conf

  4. Change the data channel’s authentication digest to SHA-512, a SHA-2 hash function. SHA-1 is the default; see openvpn --show-digests for all supported digests.

    1
    echo 'auth SHA512' >> /etc/openvpn/server.conf

  5. Restrict the VPN’s control channel to strong cipher suites. It is recommended to be as restrictive as possible here, but not all cipher suites can be used with all versions of OpenVPN. Limit the pool to AES in GCM mode over TLS 1.2 using SHA 2, and both AES and Camellia in CBC mode using SHA 1 over TLS 1.0.

    1
    echo 'tls-cipher TLS-DHE-RSA-WITH-AES-256-GCM-SHA384:TLS-DHE-RSA-WITH-AES-128-GCM-SHA256:TLS-DHE-RSA-WITH-AES-256-CBC-SHA:TLS-DHE-RSA-WITH-CAMELLIA-256-CBC-SHA:TLS-DHE-RSA-WITH-AES-128-CBC-SHA:TLS-DHE-RSA-WITH-CAMELLIA-128-CBC-SHA' >> /etc/openvpn/server.conf


    The default cipher suite used for the control channel is one agreed on by both server and client during the TLS handshake; usually this will be AES-CBC-SHA 1 over TLS 1. The agreement is based on what is supported by their respective OpenSSL versions. See openvpn --show-tls for a list of supported ciphers in their order of preference.

Certificate and Key Pairs

From here, it’s necessary to work out of the easy-rsa directory, so be sure you’re in that location:

1
cd /etc/openvpn/easy-rsa

Server Credentials

  1. A root certificate, sometimes also caled a Certificate Authority, is the certificate and key pair that will be used to generate client keypairs. At each prompt, add or edit the information to be used in your certificate (or leave them blank). Use your server’s hostname or some other identifer as the Common Name and leave the challenge password blank.

    1
    ./build-ca

  2. Then create the server’s private key; again add or edit at the information prompts as needed:

    1
    ./build-key-server server


    When you’ve completed the question section for the private key, confirm the signing of the certificate and the certificate requests certified by answering yes to those two questions.

Client Credentials

Each client device connecting to the VPN should have its own unique key. Furthermore, each key should have its own identifier (client1, client2, etc.) but all other certificate information can remain the same. If you need to add users at any time later, just repeat this step.

1
cd /etc/openvpn/easy-rsa && source ./vars && ./build-key client1

Anyone with access to client1.key will be able to access your VPN. To better protect against this scenario, you can issue ./build-key-pass client1 instead to build a client key which is encrypted with a passphrase.

Client Configuration File

Each client needs a configuration file defining the OpenVPN server’s settings for it. It’s a good idea to keep a copy of your client config file on the server as a template in case more clients are added in the future. It can not be located in /etc/openvpn, because then the OpenVPN daemon won’t know whether to load client.conf or server.conf. For this reason, we’ll store it in the keys folder with the other client files, even though the file does not need to be kept secret.

  1. Copy the client.conf template file and open it for editing. Most clients require a .ovpn file format instead of .conf, and the file extension can be changed during extraction:

    1
    cp /usr/share/doc/openvpn/examples/sample-config-files/client.conf /etc/openvpn/easy-rsa/keys/client.ovpn

  2. Update the remote line with the OpenVPN server’s IP address:

    /etc/openvpn/easy-rsa/keys/client.ovpn
    1
    2
    3
    4
    5
    # The hostname/IP and port of the server.
    # You can have multiple remote entries
    # to load balance between the servers.

    remote 192.0.2.0 1194


    A hostname would work too, but since all Linodes have static public IP addresses, it’s preferable for security reasons to connect by IP and bypass the DNS lookup.

  3. Tell the client-side OpenVPN service to drop root priviledges. For non-Windows machines only.

    /etc/openvpn/easy-rsa/keys/client.ovpn
    1
    2
    3
    # Downgrade privileges after initialization (non-Windows only)
    user nobody
    group nogroup

  4. Further down in the file, edit the crt and key lines to reflect the names and locations on the client device. Specify the path to the files if they, and client.ovpn, will not be stored in the same folder.

    /etc/openvpn/easy-rsa/keys/client.ovpn
    1
    2
    3
    4
    5
    6
    7
    8
    9
    # SSL/TLS parms.
    # See the server config file for more
    # description.  It's best to use
    # a separate .crt/.key file pair
    # for each client.  A single ca
    # file can be used for all clients.
    ca /path/to/ca.crt
    cert /path/to/client1.crt
    key /path/to/client1.key

  5. Tell the client to use the HMAC key generated earlier. Again specify the path if necessary.

    /etc/openvpn/easy-rsa/keys/client.ovpn
    1
    2
    3
    # If a tls-auth key is used on the server
    # then every client must also have the key.
    tls-auth /path/to/ta.key 1

  6. Since the VPN server was told to force certain cryptographic settings in its config file, the clients must have the same settings. Add these lines to the end of client.ovpn:

    1
    2
    cipher AES-256-CBC
    auth SHA512


    If you added any lines for Control Channel cipher suites to the server above (step 5 of Harden OpenVPN), add those lines to client.ovpn too:

    1
    tls-cipher TLS-DHE-RSA-WITH-AES-256-GCM-SHA384:TLS-DHE-RSA-WITH-AES-128-GCM-SHA256:TLS-DHE-RSA-WITH-AES-256-CBC-SHA:TLS-DHE-RSA-WITH-CAMELLIA-256-CBC-SHA:TLS-DHE-RSA-WITH-AES-128-CBC-SHA:TLS-DHE-RSA-WITH-CAMELLIA-128-CBC-SHA

  7. Pack all the necessary client files into a tarball ready for transferring. The specific files are:

    • /etc/openvpn/easy-rsa/keys/ca.crt
    • /etc/openvpn/easy-rsa/keys/client1.crt
    • /etc/openvpn/easy-rsa/keys/client1.key
    • /etc/openvpn/easy-rsa/keys/client.ovpn
    • /etc/openvpn/easy-rsa/keys/ta.key
    1
    tar -C /etc/openvpn/easy-rsa/keys -cvzf /etc/openvpn/client1.tar.gz {ca.crt,client1.crt,client1.key,client.ovpn,ta.key}


    Windows will need 7zip to extract .tar files, or you can use the package zip to create a .zip archive.

  8. You no longer need to be root, so exit back to your standard user:

    1
    exit


Initial Startup

Start the OpenVPN daemon and enable it on reboot:

1
sudo systemctl enable openvpn.service && sudo systemctl start openvpn.service

This will scan the /etc/openvpn directory on the server for files with a .conf extension. For every file that it finds, it will spawn a VPN daemon (server instance) so make sure you don’t have a client.conf or client.ovpn file in there.

Monitoring OpenVPN for Issues

The logs of both the OpenVPN client and servers will contain all the information you need to confirm connection specifications, view client address assignments and debug connection issues. Even if the connection completes seemingly without problems, the logs can contain alerts and messages for how to better configure your setup.

To check the status of the OpenVPN process:

1
sudo systemctl status openvpn*.service

That should return:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
● openvpn.service - OpenVPN service
   Loaded: loaded (/lib/systemd/system/openvpn.service; enabled)
  Active: active (exited) since Tue 2015-10-13 20:55:13 UTC; 14min ago
 Process: 5698 ExecStart=/bin/true (code=exited, status=0/SUCCESS)
Main PID: 5698 (code=exited, status=0/SUCCESS)
  CGroup: /system.slice/openvpn.service

Oct 13 20:55:13 localhost systemd[1]: Stopping OpenVPN service...
Oct 13 20:55:13 localhost systemd[1]: Starting OpenVPN service...
Oct 13 20:55:13 localhost systemd[1]: Started OpenVPN service.

● openvpn@server.service - OpenVPN connection to server
   Loaded: loaded (/lib/systemd/system/openvpn@.service; disabled)
   Active: active (running) since Tue 2015-10-13 20:55:13 UTC; 14min ago
 Process: 5709 ExecStart=/usr/sbin/openvpn --daemon ovpn-%i --status /run/openvpn/%i.status 10 --cd /etc/openvpn --config /etc/openvpn/%i.conf (code=exited, status=0/SUCCESS)
Main PID: 5725 (openvpn)
  CGroup: /system.slice/system-openvpn.slice/openvpn@server.service
       └─5725 /usr/sbin/openvpn --daemon ovpn-server --status /run/openvpn/server.status 10 --cd /etc/openvpn --config ...

Use sudo journalctl -f | grep vpn to monitor the logs of your OpenVPN server in realtime; press Control+C to stop monitoring.

Next Steps

At this point, you should have a operational OpenVPN server and a set of certificate/key pairs for your intended client devices.

If you want your server to forward and receive traffic to/from the internet on behalf of VPN clients, see part two of this series: Tunnel Your Internet Trafic Through an OpenVPN Server.

If you intend to use your OpenVPN server as an extension of your local network or host services you want to access from your LAN, you would need to configure the specific applications for your use. To set up the connecting client devices, see part three: Configuring OpenVPN Client Devices.

More Information

You may wish to consult the following resources for additional information on this topic. While these are provided in the hope that they will be useful, please note that we cannot vouch for the accuracy or timeliness of externally hosted materials.

This guide is published under a CC BY-ND 4.0 license.
